Pulse Valve
Valve for Dust Collector
Long service life:
Spring is not necessary due to high strength
elastomer diaphragm.
∗ Value based on the test conditions of SMC (3/4 inch, 20A)
(except the made-to-order "A")
OFF response time:
∗
45
1, 2
% reduction

Fluid temperature:

− 40 to 60°
Applicable for wide range of temperature
Easier maintenance
Springless diaphragm allows for easy maintenance of valve.
Main valve and sub-valve (for 40A) included in maintenance kit
∗1 Based on SMC's specific testing conditions
(JSXFA-06, Pilot valve orifice is ø5 mm or larger)
∗2 Comparison with SMC existing model
Variations
Piping
Compression fitting type
Direct piping type
(Rc, NPT, G)
Compression fitting type
JSXFAE
Series
Dedicated Controller for Operation VXFC
The valve controller turns ON/OFF many valves for the dust controller.
Power supply
85 to 240 VAC
voltage 12 VDC, 24 to 48 VDC
1
JSXFA
10
million cycles
IN port
3/4, 1, 1 1/2 (20A, 25A, 40A)
C
Orifice diameter
Port size
3/4
(20A)
1
(25A)
1 1/2
(40A)
Number of
6 output points,
output points 10 output points
Series
∗
1
or more
Steel tube
piping
Flow rate characteristics:
∗
40
1, 2
%
Optimum design for the internal geometry
Thread type
[mm]
ø32
Rc
ø40 NPT
G
ø50
Direct piping type
JSXFAF
Series
9
p.
Series
Pilot port
1/8, 1/4 (Rc, NPT, G)
OUT port
3/4, 1, 1 1/2 (20A, 25A, 40A)
increase
With/without silencer
Pilot port size
(Option)
Without
1/8
Without
1/4
With
