- Page 1 NN61536600 Doc. No. DOC1042447 PRODUCT NAME Pulse Valve SMARTVENT Type MODEL / Series / Product Number JSXF Series...
- Page 2 Contents ....................Contents Safety Instructions ..........................P2,3 1.Precautions for Design ......................P4 2.Precautions for Operating Environment .................. P4,5 3.Precautions for Fluid ........................ P5 4.Material of Fluid ........................P5 5.Precautions for Mounting ...................... P5,6 6.Precautions for Piping ......................P6,7 7.Precautions for Wiring ......................P8 8.Notes on Appearance ......................
- Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
- Page 5 The solenoid coil generates heat if continuously energized. Do not use the product in sealed containers. Install the product in a ventilated location. Do not touch the valves with bare hand during or after energization. 5. Dual pressure If there is a possibility that reverse pressure will be applied, take countermeasures such as mounting a check valve on the outlet side of the valve.
- Page 6 ‐ ̀ Ȃ...
- Page 7 Proper tightening torque Thread N·m 8 to 12 15 to 20 20 to 25 28 to 30 36 to 38 1･1/2 40 to 42...
- Page 8 1. Do not use the compression fitting of the valve to support the valve piping. The piping may be disconnected from the valve. Be sure to mount the valve to the fixed piping. (The compression fitting does not have a function to secure and hold the valve.) Additional Size tightening...
- Page 9 1. A surface treatment is applied to the product to improve corrosion resistance. There may be a spot pattern on the surface depending on the treatment condition, but there is no problem in use.
- Page 11 -10-...
- Page 12 12. Specifications Common specifications JSXF□□-□□□-5PRB-□□ Product number JSXF□□-□□□-5(PP/PB)B-□□ Remote valve Valve Base valve Valve construction Pilot diaphragm Valve type Valve open when energized (Normally Closed) Fluid Withstand pressure 1.5 MPa Minimum operating pressure 0.1 MPa Maximum operating pressure 0.9 MPa Maximum system pressure 0.9 MPa Fluid temperature...
- Page 13 JSXFE/F Series Orifice diameter (mm) Ø 32 Ø 40 Ø 50 Port size 1･1/2 Compression 1,240 1,680 2,620 Weight (g) Direct port 1,060 1,250 2,000 JSXFH Series Orifice diameter (mm) Ø 32 Ø 40 Ø 45 Ø 55 Port size 1･1/2 Tank size ANSI...
- Page 14 14. Dimensions -13-...
- Page 15 -14-...
- Page 16 Hexagon Tightening socket torque 0.4 N·m±10% -15-...
- Page 17 Supported lead wire AWG 26 to 16 Recommended strip length 5 mm Tightening torque for the terminal block 0.22 N·m to 0.25 N·m -16-...
- Page 18 Name Mark Description Connect 24 VDC. The connected voltage is supplied to the base Power terminal and remote valves. block When connecting, pay attention to the polarity (+, −). A terminal block to connect with a remote valve. Connect to the BUS connection terminal block of the remote valve.
- Page 19 16.2. Board for remote valves Name Mark Description A connection terminal for the base valve or a remote valve. When connecting,, pay attention to the polarity (+, S, −). terminal block "+" and "−" are used to supply power to the remote valve, and "S"...
- Page 20 17.1. Continuous operation mode In this mode, the base valve and remote valves will continue operating as long as the power supply voltage is applied. The cycle operation, in which address 1 → address 31 are turned ON in order starting with the base valve as one cycle, continues while the power supply voltage is being applied.
- Page 21 ・ → → *As shown in the figure above, if an address is empty, the remote valve set in the next address automatically turns ON. ・When using the base valve and 31 remote valves: Base: ON → Address 1: ON → Address 2: ON... → Address 31: ON → Base: ON → .. -20-...
- Page 22 17.3. How to set a mode Note) Before setting a mode, be sure to shutting off the power supply to valves. Note) Use an appropriate screwdriver for the groove and do not apply an excessive stress. 17.3.1. ON setting switch (Base valve) Use the ON setting switch to set the valve ON time.
- Page 23 Use the differential pressure switch to switch from continuous operation mode to differential pressure detection mode. Set the differential pressure threshold at which to start operation by setting 1 to F in differential pressure detection mode. If the output from the connected differential pressure sensor (two- wire system, 4 to 20 mA output) is above the threshold, the continuous operation mode starts.
- Page 24 17.3.4. Address setting switch (Remote valves) Check the table below to set the addresses for remote valves. It is set to "Address: None" at a time of shipment from the factory. Note) Be aware that a remote valve which is set to "Address: None" will not operate and will be skipped even when it is connected.
- Page 25 Replacement parts product No. Sub-valve Size Product No. Main valve assembly assembly Silencer-1 Silencer-2 (Main valve + O-ring) (Sub-valve + O-ring) － Port size: 06 JSXF(E,F,H)*-06*-5P*B-(S)* JSXF-06B-KT Rc/G thread: AN20-02 － － Port size: 10 JSXF(E,F,H)*-10*-5P*B-(S)* JSXF-10B-KT NPT thread: AN20-N02 JSXF(E,F)*-14*-5P*B-(S)* JSXF-14B-KT Port size: 14...
- Page 26 1) Loosen the nuts and remove the two hexagon socket head set screws so that the box assembly can be rotated. 2) Rotate the box assembly clockwise and screw it in to the end. 3) Rotate the box assembly counterclockwise to adjust it to the desired position.
- Page 27 20. Trouble Check Sheet (target series: JSXF：SMARTVENT) Warranty period: Within 1.5 years after the product is delivered or 1 year in service. Refer to and use this trouble check sheet as a cause diagnosis check sheet when a trouble has occurred to solve it early. Part that could be the Phenomenon Possible causes...
- Page 28 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2023 SMC Corporation All Rights Reserved...
