Dimensions
Rotary switch for setting output
Pressure Terminology
1. Maximum operating pressure differential
The maximum pressure differential (the difference between the
inlet and outlet pressure) which is allowed for operation. When
the outlet pressure is 0 MPa, this becomes the maximum oper-
ating pressure.
2. Minimum operating pressure differential
The minimum pressure differential (the difference between the
inlet pressure and outlet pressure) required to keep the main
valve fully open.
3. Maximum system pressure
The maximum pressure that can be applied inside the pipe-
lines (line pressure).
[The pressure differential of the solenoid valve portion must
not exceed the maximum operating pressure differential.]
Dedicated Controller for Operation
Digital switch for setting OFF time
Digital switch for setting ON time
ON OFF
SW1
SW8
0 0 0 0 0 0
sec sec
0.01 to 0.99 0 to 299
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8 LED9 LED10
SV2 SV4 SV6
SV1 SV3 SV5
5
Output terminal block Common terminal block
JSXFA
Series
DIP switch for setting cascade
DIP switch for setting two-time hitting
Terminal block for cascade connection
OUT1 OUT2 IN1 IN2
SW2
LED LED LED LED
11 12 13 14
OUT CAS IN POW
ON
1A
OFF
SV8 SV10 COM AC1 AC2 FG
SV7 SV9
5
140
Power supply terminal block
/ Glossary of Terms
1. Symbol
In the symbol (
blocked from port 1 to port 2. However, if the pressure in port 2
is higher than port 1, the valve will not be able to block the fluid
and it will flow from port 2 to port 1.
VXFC
Series
Power supply switch
4 x ø4.5
Other
), when the valve is closed, flow is
