- Page 1 NN59366100 Doc. no.DOC1029458 PRODUCT NAME Pilot Operated 2 Port Solenoid Valve MODEL / Series / Product Number JSXD series...
-
Page 2: Table Of Contents
Contents Contents・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・ P1 Safety Instructions ・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2,3 1. Precautions for Design・・・・・・・・・・・・・・・・・・・・・・・・・・ P4 2. Operating environment・・・・・・・・・・・・・・・・・・・・・・・・・・ P5 3. Precautions for Fluid・・・・・・・・・・・・・・・・・・・・・・・・・・・ P6 4. Fluid quality・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P6 5. Mounting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P7 6. Bracket mounting・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 7. Piping・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P8,9 8. Wiring・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 9. Electric connection・・・・・・・・・・・・・・・・・・・・・・・・・・ ・ P10～12 10. -
Page 3: Safety Instructions ・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2,3
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
-
Page 5: Precautions For Design・・・・・・・・・・・・・・・・・・・・・・・・・・ P4
1. Precautions for Design Warning 1. Check the specifications. Fully understand the applications, fluids, environment, and other operating conditions to use this product within the specified range shown in this catalog. Operation outside of the product operating range may cause damage to the product or operation failure. SMC does not guarantee against any damage if the product is used outside of the specification range. -
Page 6: Operating Environment・・・・・・・・・・・・・・・・・・・・・・・・・・ P5
2. Operating environment Warning Do not use this product at the location described below. ①Location where the product may be exposed to an atmosphere containing steam, corrosive fluid (chemicals), seawater, or water. Take appropriate protective measures in environments where the product is exposed to water for a long time even for products with protection codes (IP65, IP67). -
Page 7: Precautions For Fluid・・・・・・・・・・・・・・・・・・・・・・・・・・・ P6
3. Precautions for Fluid Warning Selection of fluid Compatibility between the component materials of the product and fluids should be checked in the actual application before use. The compatibility of the fluid may differ according to the type, additives, concentration, temperature, and other conditions. -
Page 8: Mounting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P7
5. Mounting Warning When mounting the products, allow enough space to provide access for maintenance. Avoid sources of vibration or adjust the arm from the body to the minimum length to prevent the generation of resonance. Do not install the product near a heat source or a location exposed to radiant heat. Do not apply external force to the coil section. -
Page 9: Piping
7. Piping Warning Tubing may detach abruptly from the fitting while the product is in use due to degradation of the tube or fitting breakage. To prevent abrupt detachment, install a protective cover or fix the tube securely. For piping the tube, fix the product securely using the mounting holes on the bottom of the body or a bracket to prevent the product from being lifted. - Page 10 Recommended piping conditions When connecting piping to a One-touch fitting, use pipe length with sufficient margin in accordance with the piping conditions shown in Fig. 1. Also, when using a tying band or a similar item to bind the piping together, make sure that external force will not be applied to the fitting.
-
Page 11: Wiring
8. Wiring Warning Solenoid valves are electrical products. Install an appropriate fuse and circuit breaker for safety. Caution Use wiring cable with a conductor cross-section of 0.5 to 1.25 mm External force on the lead wire Excessive force applied to the lead wire may break the wire. - Page 12 DIN terminal Disassembly Loosen the binding head screw with the flange and pull up the housing in the direction of the arrow to remove the connector from the solenoid valve. Pull out the binding head screw with the flange from the housing. Detach the terminal block from the housing using the recess at the bottom of the terminal block, using a flat-blade screwdriver.
-
Page 13: Electric Circuit・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P112
M12 connector 1. IP67 (protection structure) of the valve can be achieved by using a female connector (with a cable) of the IP67 specification. However, do not use the product underwater. 2. Mounting a connector using tools may break the connector. Securely tighten the connector manually. (0.39~0.49N･m) 3. -
Page 14: Return Of Product・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P13
11. Maintenance Warning Detaching of the product Shut off the fluid supply and discharge the fluid pressure in the system. Shut down the power. Check that the valve temperature has decreased sufficiently and detach the product. Regularly replace or clean the filter (strainer). Replace the filter after a year of use or earlier if the pressure drop reaches 0.1 MPa. -
Page 15: Models
14. Models Model indication method - 14 -... - Page 16 Flow-rate characteristics 15. Specifications - 15 -...
- Page 17 16. Construction - 16 -...
-
Page 18: Definition And Terminology・・・・・・・・・・・・・・・・・・・・・・・・ P17
17. Definition and Terminology Maximum The maximum pressure difference (difference between the inlet operating pressure and outlet pressure) that is allowed for operation. When the pressure outlet pressure is 0 MPa, it becomes the maximum operating pressure. differential Minimum The minimum pressure difference (difference between the inlet operating pressure and outlet pressure) required for stable operation of the main pressure... - Page 19 18. Trouble Check Sheet (target series: JSXD) Operating conditions Deliver date MM/DD, YYYY Operating period months Accumulated operating Approx. cycles cycles Warranty period: Within 1.5 years after the product is delivered or 1 year in service. Refer to and use this trouble check sheet as a cause diagnosis check sheet when a trouble has occurred to solve it early. Phenomenon Condition check Possible cause...
- Page 20 Phenomenon Condition check Possible cause Countermeasures Is there any abnormality, such as failure, with the There is a possibility of an abnormality with the power supply, power supply or control circuit? □ → control circuit, or wiring system. Is there any abnormality, such as broken wire or mis The power supply (1) Replace or repair the power supply, control circuit, or wiring system.
- Page 21 Phenomenon Condition check Possible cause Countermeasures Is the fluid or ambient temperature above the operating The rubber seal part may be deteriorated due to high temperature. □ □ → temperature range upper limit? (1) Use the product within the operating temperature range. Leakage Deterioration and from...
- Page 22 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2023 SMC Corporation All Rights Reserved...
