SMC Networks JSY1000 Series Operation Manual

Solenoid valve (non plug-in)
Hide thumbs Also See for JSY1000 Series:

Advertisement

Quick Links

Doc. No.JSY1000V-OMW0004
Solenoid Valve
PRODUCT NAME
JSY1000/3000/5000 Series
(Non Plug-in)
MODEL/ Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JSY1000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks JSY1000 Series

  • Page 1 Doc. No.JSY1000V-OMW0004 Solenoid Valve PRODUCT NAME JSY1000/3000/5000 Series (Non Plug-in) MODEL/ Series...
  • Page 2: Table Of Contents

    Contents Contents ---------------------------------------------------------------------------------------------- Safety Instructions ---------------------------------------------------------------------------------- 2,3 Design / Selection ----------------------------------------------------------------------------------- 4 to 6 Mounting -------------------------------------------------------------------------------------------- 6 Piping ------------------------------------------------------------------------------------------------ 6,7 Wiring ------------------------------------------------------------------------------------------------ 7 Lubrication ------------------------------------------------------------------------------------------ 7 Air Supply ---------------------------------------------------------------------------------------------- 7,8 Operating Environment ----------------------------------------------------------------------------- 8 Maintenance ------------------------------------------------------------------------------------------- 9 Specific Product Precautions --------------------------------------------------------------------- 10 to 14 Valve Construction ----------------------------------------------------------------------------------- 15 Valve Replacement Parts / Pilot Valve ---------------------------------------------------------- 16 Manifold exploded view ----------------------------------------------------------------------------- 17...
  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5 JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 1 Be sure to read before handling. Refer to main text for detailed precautions on every series. 9. Regarding a vacuum switch valves and Design / Selection vacuum release valves Warning If a non-vacuum valve is installed in the middle of a piping system that contains a vacuum, the vacuum 1.
  • Page 6 JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 2 Be sure to read before handling. Refer to main text for detailed precautions on every series. Design / Selection 4. Surge voltage intrusion With non-polar type solenoid valves, at times of sudden interruption of the loading power supply, such Caution as emergency shutdown, surge voltage intrusion may...
  • Page 7: Design / Selection

    JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 3 Be sure to read before handling. Refer to main text for detailed precautions on every series. Design / Selection Piping Caution Caution 1. Refer to the Fittings and Tubing 6. Operation for air blowing Precautions for handling one-touch When using a solenoid valve for air blowing, use an fittings.
  • Page 8: Wiring

    JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 4 Be sure to read before handling. Refer to main text for detailed precautions on every series. No diode to protect polarity. Piping If a mistake is mode regarding the polarity, damage may occur to the diode in the valve, the switching Caution element in a control device or power supply equipment,...
  • Page 9: Operating Environment

    JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 5 Be sure to read before handling. Refer to main text for detailed precautions on every series. 4. The valve should not be exposed to prolonged sunlight. Air Supply Use a protective cover. Note that the valve is not for Warning outdoor use.
  • Page 10: Maintenance

    JSY1000/3000/5000 Series Precautions for 5 Port Solenoid Valve 6 Be sure to read before handling. Refer to main text for detailed precautions on every series. Maintenance Warning 1. Perform maintenance and inspection according to the procedures indicated in the operation manual. If handled improperly, human injury and/or malfunction or damage of machinery and equipment may occur.
  • Page 11 JSY1000/3000/5000 series Specific Product Precautions 1 Be sure to read this before handling. 。 Environment Caution ■Push-turn locking slotted type [D type] Warning Push down on the manual override with a small flat head screwdriver until it stops, and then turn it 90° clockwise. Do not use valves in atmospheres of corrosive gases, The manual override is then locked.
  • Page 12 JSY1000/3000/5000 series Specific Product Precautions 2 Be sure to read this before handling. 。 2. Crimping connection of lead wire and socket Used as a 3-Port Valve Strip 3.2 to 3.7 mm at the end of lead wires, insert the end of the core wires evenly into the sockets, and then crimp it Caution by a crimping tool.
  • Page 13 JSY1000/3000/5000 series Specific Product Precautions 3 Be sure to read this before handling. 。 Plug Connector Surge Voltage Suppressor - 12 - No.JSY1000V-OMW0004...
  • Page 14 KQSY11-C6-X1336 (JSY1000) KQSY30-C8-X1336 (JSY3000) KQSY50-C12-X1336 (JSY5000) * It is not possible to replace C2 or C4 fittings with C6 fittings for the JSY1000 series. * Refer to page 18 for One-touch fitting, clip, and port plate part numbers. - 13 -...
  • Page 15: Specific Product Precautions 5

    JSY1000/3000/5000 series Specific Product Precautions 5 Be sure to read this before handling. 。 Other Tube Brands Caution When using other than SMC brand tube, confirm that the following specifications are satisfied with respect to the tube outside diameter tolerance. 1) Nylon tube within ±0.1 mm 2) Soft nylon tube...
  • Page 16: Valve Construction

    JSY1000/3000/5000 series Specific Product Precautions 1 Be sure to read this before handling. 。 Environment Caution ■Push-turn locking slotted type [D type] Warning Push down on the manual override with a small flat head screwdriver until it stops, and then turn it 90° clockwise. Do not use valves in atmospheres of corrosive gases, The manual override is then locked.
  • Page 17: Valve Replacement Parts / Pilot Valve

    JSY1000/3000/5000 series Specific Product Precautions 2 Be sure to read this before handling. 。 2. Crimping connection of lead wire and socket Used as a 3-Port Valve Strip 3.2 to 3.7 mm at the end of lead wires, insert the end of the core wires evenly into the sockets, and then crimp it Caution by a crimping tool.
  • Page 18: Manifold Exploded View

    JSY1000/3000/5000 series Specific Product Precautions 3 Be sure to read this before handling. 。 Plug Connector Surge Voltage Suppressor - 12 - No.JSY1000V-OMW0004...
  • Page 19: One-Touch Fittings, Clip, Port Plate, Tube Releasing Tool

    KQSY11-C6-X1336 (JSY1000) KQSY30-C8-X1336 (JSY3000) KQSY50-C12-X1336 (JSY5000) * It is not possible to replace C2 or C4 fittings with C6 fittings for the JSY1000 series. * Refer to page 18 for One-touch fitting, clip, and port plate part numbers. - 13 -...
  • Page 20: Manifold Option

    JSY1000/3000/5000 series Specific Product Precautions 5 Be sure to read this before handling. 。 Other Tube Brands Caution When using other than SMC brand tube, confirm that the following specifications are satisfied with respect to the tube outside diameter tolerance. 1) Nylon tube within ±0.1 mm 2) Soft nylon tube...
  • Page 21 - 21 - No.JSY1000V-OMW0004...
  • Page 22: Trouble Shooting

    - 22 - No.JSY1000V-OMW0004...
  • Page 23 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2020 SMC Corporation All Rights Reserved No.JSY1000V-OMW0004...
