Technical Specifications - Omcan MS-IT-0300-IP Instruction Manual

Safety and Warranty
ENVIRONMENTAL CONDITIONS OF USE
Temperature: from -5 °C a + 40 °C
Relative humidity: max 95%
OPENING THE BOX
On reception check packaging integrity, otherwise inform the forwarding agent or
the area agent immediately.
To unpack the machine, proceed as follows:
• Open the box and remove your copy of the manual of use and maintenance,
then proceed according to the instructions found on that manual;
• Lift the machine still wrapped in a transparent polyethylene sheet and extract
it from the box;
• Now check the box content and make sure it corresponds to what shown on
the external label.
WARNING:
The packaging components (cardboard, polyethylene, and others) are classified as normal solid urban waste
and can therefore be disposed of without difficulty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specifications

Model
Blade Size
Cut Thickness
Cutting Size
Power
RPM
Electrical
Weight
Dimension (WDH)
Item Numbers
MS-IT-0300-IP
12" / 300mm
0 - 16mm
11.25" x 9"
0.50 HP / 0.37 kW
280
110V / 60Hz / 1
79.3 lbs.
30.31" x 21.25" x 18.30"
13629
MS-IT-0330-L
13"/330mm
0-16mm
11.25" x 9.84"
0.50 HP / 0.37 kW
280
110V/ 60Hz / 1
85 lbs.
30.31" x 21.65" x 18.30"
13635
6
MS-IT-0350-L
14"/350mm
0 - 16mm
12.75" x 10.25"
0.50 HP / 0.37 kW
286
110V/ 60Hz / 1
97 lbs.
22.83" x 23" x 19"
13637
