Omcan MS-IT-0300-IP Instruction Manual page 21

Model MS-IT-0350-L
Item No. Description
15204 Housing for 350F
34736 Screw for 350F
34737 Stop Plate for 350F
34738 Strain Relief for 350F
34739 Set Screw for 350F
34740 Bushing for 350F
34741 Set Screw for 350F
15205 Tie Rod for 350F
34742 Nut for 350F
34743 Tie Rod Knob for 350F
34744 Foot for 350F
34745 Sharpener Support Bracket for 350F
34746 Sharpener Tie Rod for 350F
34747 Washer for 350F
34748 Screw TE for 350F
34749 Screw TC for 350F
34750 Washer for 350F
34751 Sharpener Support Pin for 350F
34752 Sharpener Screw for 350F
34753 Screw TC for 350F
34754 Washer for 350F
34755 Sharpener Pin for 350F
34756 Sharpening Stone for 350F
34757 Nut for 350F
34758 Set Screw for 350F
34759 Sharpener Spring for 350F
34760 Ball Bearing for 350F
34761 Screw for 350F
34762 Sharpener Push Button for 350F
34763 Washer for 350F
34764 Screw TC for 350F
34765 Sharpener Body for 350F
34766 Sharpener Pin for 350F
34767 Sharpening Stone for 350F
34768 Sharpener Cover for 350F
34769 Small Bushing for 350F
34770 Clip for 350F
13637
Position Item No. Description
A1 34771 Clip for 350F
A2 34772 Bearing for 350F
A3 15206 Bearing Spacer for 350F
A4 34773 Bearing and Shaft for 350F
A5 34774 Belt for 350F
A6 34775 Spindle Pulley for 350F
A7 34776 Set Screw for 350F
A8 34777 Blade for 350F
A9 34778 Screw for 350F
A10 34779 Blade Shield for 350F
A11 34780 Thumb Screw for 350F
A12 34781 Meat Grip for 350F
A13 34782 Set Screw for 350F
A14 34783 Washer PVC for 350F
A15 34784 Rubber Washer for 350F
A16 34785 Meat Grip Spring for 350F
A17 34786 Meat Grip Handle Screw for 350F
A18 34787 Meat Grip Handle for 350F
A19 34788 Meat Grip Support Shaft for 350F
A20 34789 Meat Tray Adjustment Plate for 350F
A21 34790 Set Screw for 350F
A22 34791 Set Screw for 350F
A23 37448 Meat Tray for 350F
A24 34792 Sharpener Tie Rod for 350F
A25 34793 Pin for 350F
A26 34794 Meat Tray Support Arm for 350F
A27 34795 Carriage Knob for 350F
A28 15207 Carriage Handle for 350F
A29 34796 Nut for 350F
A30 34797 Guide Plate for 350F
A31 34798 Guide Plate Support for 350F
A32 34799 Screw TE for 350F
A33 34800 Wavy Washer for 350F
A34 34801 Cam for 350F
A35 34802 Set Screw - Capped for 350F
A37 15208 Guide Plate Pin for 350F
A38 34803 Cam Guide for 350F
Parts Breakdown
Position Item No.
A39 34805
A40 34806
A41 34807
A42 34808
A43 34809
A44 34810
A45 34811
A46 34812
A47 34813
A48 34814
A49 21657
A50 34815
A51 34816
A52 21658
A53 34817
A54 15209
A55 34818
A56 34819
A57 34820
A58 34821
A59 34822
A60 34823
A61 34824
A62 15210
A63 34825
A64 34826
A65 34827
A66 34828
A67 31235
A68 34829
A69 34830
A70 34831
A71 14859
A72 37449
A73 15211
A74 34804
A75 15212
21
Description Position
Set Screw for 350F A76
Cam Plate for 350F A77
Screw for 350F A78
Screw TC for 350F A79
Index Knob for 350F A80
White Bushing for 350F A81
Copper Rivet for 350F A82
Meat Deflector for 350F A83
Deflector Screw for 350F A84
Screw Chrome for 350F A85
Carriage for 350F A86
Screw TC for 350F A87
Pin for 350F A88
Bearing for 350F
A89
Set Screw for 350F A90
Carriage Support for 350F A91
Set Screw PVC for 350F A92
Slide Bar Spring for 350F A93
Carriage Slide Bar for 350F A94
Indicator Light for 350F A95
Switch - On / Off for 350F A96
Screw TC for 350F A97
Capacitor Bracket for 350F A98
Capacitor for 350F A99
Wing Nut for 350F A100
Motor Bracket for 350F A101
Screw for 350F A102
Motor for 350F A103
Adjustment Rod for 350F A104
Washer for 350F A105
Hinge for 350F A106
Motor Support Shaft for 350F A107
Power Cord 110V for 350F A109
Bottom Cover for 350F C4
Complete Pulley Assy. for 350F
Complete Cam Assy. for 350F
Complete Sharpening Assy. for 350F
