Omcan MS-IT-0300-IP Instruction Manual page 17

Model MS-IT-0300-IP
Item No. Description
34442 Housing for 300F
34443 Screw for 300F
34444 Nut for 300F
34445 Guide Plate Pin for 300F
34446 Strain Relief for 300F
34447 Set Screw for 300F
34448 Set Screw for 300F
15163 Tie Rod for 300F
34449 Nut for 300F
34450 Tie Rod Handle for 300F
34451 Sharpener Tie Rod for 300F
34452 Sharpener Support Bracket for 300F
34453 Washer for 300F
34454 Screw TE for 300F
34455 Sharpener Support Shaft for 300F
34456 Sharpener Pin Spacer for 300F
34457 Sharpener Pin for 300F
34458 Sharpening Stone for 300F
34459 Washer for 300F
34460 Set Screw for 300F
34461 Nut for 300F
34462 Screw TGS for 300F
34463 Sharpener Push Button for 300F
34464 Ball Bearing for 300F
34465 Sharpening Stone for 300F
34466 Sharpener Pin for 300F
34467 Sharpener Pin Spring for 300F
34468 Sharpener Cover for 300F
34469 Sharpener Body for 300F
34470 Sharpener Pin Spacer for 300F
34471 Washer for 300F
34472 Screw TC for 300F
34473 Sharpener Push Button for 300F
34474 Sharpener Pin Spring for 300F
34475 Set Screw for 300F
34476 Stud Screw for 300F
13629
Position Item No. Description
A1 34477 Washer for 300F
A2 34478 Screw TC for 300F
A3 34479 Clip for 300F
A4 34480 Clip for 300F
A5 34481 Bearing for 300F
A6 34482 Spacer for 300F
A7 23741 Belt for 300F
A8 15164 Spindle Pulley for 300F
A9 34483 Bearing and Shaft for 300F
A10 13596 Blade for 300F
A11 34485 Screw TPSV for 300F
A12 15165 Blade Shield for 300F
A13 34486 Rubber Washer for 300F
A14 34487 Meat Grip for 300F
A15 34488 Meat Carriage Shaft Spring for 300F
A16 14893 Meat Grip Handle for 300F
A17 14894 Meat Grip Handle Screw for 300F
A18 34490 Plastic Dowel for 300F
A19 18936 Meat Carriage Shaft for 300F
A20 21256 Meat Carriage for 300F
A21 34491 Set Screw for 300F
A22 34492 Guide Plate for 300F
A23 34493 Meat Carriage Support for 300F
A24 15070 Carriage Knob for 300F
A25 15167 Meat Carriage Handle for 300F
A26 34495 Wavy Washer for 300F
A27 34496 Set Screw for 300F
A28 34497 Cam for 300F
A29 34498 Cam Screw for 300F
A30 34499 Screw for 300F
A31 34500 Cam Guide for 300F
A32 34501 Screw TC for 300F
A33 34502 Cam Plate for 300F
A34 34503 Screw TC for 300F
A35 34504 Guide Plate Pin for 300F
A36 34505 Guide Plate Support for 300F
Parts Breakdown
Position Item No.
A37 34506
A38 15169
A39 15169
A40 34508
A41 34028
A42 34510
A43 34333
A44 15195
A45 15170
A46 34513
A47 34514
A48 34515
A49 34516
A50 19247
A51 18935
A52 15171
A53 34517
A54 34518
A55 15172
A56 15073
A57 34520
A58 34521
A59 34522
A60 34523
A61 34524
A62 34525
A63 34526
A64 34527
A65 34528
A66 34529
A67 15174
A68 14859
A69 37951
A70 30445
A71 76253
A72
17
Description Position
Meat Deflector for 300F A73
Screw for 300F A74
Screw TE for 300F A75
Copper Rivet for 300F A76
Index Knob for 300F A77
Screw Chrome for 300F A78
Light for 300F A79
Switch - On / Off for 300F A80
Carriage Rail for 300F A81
Bearing for 300F A82
Pin for 300F A83
Set Screw for 300F A84
Set Screw PVC for 300F A85
Slide Bar Spring for 300F
A86
Carriage Support for 300F A87
Screw TC for 300F A88
Carriage Slide Bar for 300F A89
Stop Plate for 300F A90
Tapping Screw for 300F A91
Foot for 300F A92
Capacitor for 300F A93
Capacitor Clamp for 300F A94
Screw TC for 300F A95
Motor Spring for 300F A96
Motor Bracket for 300F A97
Wing Nut for 300F A98
Washer for 300F A99
Hinge for 300F A100
Motor Support Shaft for 300F A101
Motor Tie Rod for 300F A103
Motor for 300F A104
Power Cord for 300F A105
Bottom Cover for 300F C4
Cam Assembly for 300F
Complete Sharpening Assy. for 300F
