Steelcase Elective Elements Glass Modesty Panel Assembly Instructions Manual page 9

10.
Install a pair of mounting
brackets onto the underside of top
of adjoining unit. Position brackets
(a), drill pilot holes (b), then secure
with screws provided (c).
11.
Carefully turn glass modesty
panel assembly over and attach to
adjacent unit.
TIP: Modesty Panel may overhang
the worksurface, depending on the
configuration. Install remaining #10
x .875" screws to overhanging part
of gusset (if any).
2.00"
(50 mm)
DRILL BIT
(1/8"
10b
1.00"
(25 mm)
10a
#10 x .750"
10c
pan head
screws
11
11
Page 9 of 10
939568005 Rev A
