12.
Check to see if unit is level.
13.
Slide glide cover up and use tool
provided to adjust glide.
14.
After glide is adjusted, slide glide
cover back down.
15.
Adjust column height vertically
as shown.
15
The inner leg has a vertical row of dimples that allow
adjustment by 1/4" increments up to 2-1/4" maximum.
TIP: Glide adjustment may
be necessary to improve
headset alignment.
12
Cone-point
Set Screw
use an allen wrench to
loosen set screw, then
adjust column height.
13
NOTE: Glide adjustment tool is available through
Steelcase Service Parts (part number Y565727SR)
14
939568005 Rev A
Page 10 of 10
