KA01294D/06/EN/01.17
71349570
Products
Brief Operating Instructions
Proline 300
FOUNDATION Fieldbus
Transmitter with
Electromagnetic sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Transmitter Brief Operating Instructions
Contain information about the transmitter.
Sensor Brief Operating Instructions →  3
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proline 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Proline 300

Summary of Contents for Endress+Hauser Proline 300

  • Page 1 Products Solutions Services KA01294D/06/EN/01.17 71349570 Brief Operating Instructions Proline 300 FOUNDATION Fieldbus Transmitter with Electromagnetic sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Transmitter Brief Operating Instructions Contain information about the transmitter.
  • Page 2 Proline 300 FOUNDATION Fieldbus Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 These Brief Operating Instructions are the Transmitter Brief Operating Instructions. The "Sensor Brief Operating Instructions" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer...

  • Page 4: Table Of Contents

    Table of contents Proline 300 FOUNDATION Fieldbus Table of contents Document information ............5 Symbols used .

  • Page 5: Document Information

    Proline 300 FOUNDATION Fieldbus Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 6 Document information Proline 300 FOUNDATION Fieldbus Symbol Meaning Protective ground connection A terminal which must be connected to ground prior to establishing any other connections. Equipotential connection A connection that has to be connected to the plant grounding system: This may be a potential equalization line or a star grounding system depending on national or company codes of practice.

  • Page 7: Basic Safety Instructions

    Proline 300 FOUNDATION Fieldbus Basic safety instructions Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣...

  • Page 8: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 9: Device-Specific It Security

    Proline 300 FOUNDATION Fieldbus Basic safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in-operation safety if used correctly.

  • Page 10: Product Description

    Product description Proline 300 FOUNDATION Fieldbus Product description The device consists of a Proline 300 transmitter and an electromagnetic Proline Promag sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. N ic...

  • Page 11: Installation

    Proline 300 FOUNDATION Fieldbus Installation Installation For detailed information about mounting the sensor, see the Sensor Brief Operating Instructions →  3 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned.

  • Page 12: Turning The Display Module

    Installation Proline 300 FOUNDATION Fieldbus Turning the display module The display module can be turned to optimize display readability and operability. – – – 3 mm A0030035 Loosen the securing clamp of the connection compartment cover. Unscrew the connection compartment cover.

  • Page 13: Electrical Connection

    Proline 300 FOUNDATION Fieldbus Electrical connection Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
  • Page 14 Electrical connection Proline 300 FOUNDATION Fieldbus Signal cable FOUNDATION Fieldbus Twisted, shielded two-wire cable. For further information on planning and installing FOUNDATION Fieldbus networks see: • Operating Instructions for "FOUNDATION Fieldbus Overview" (BA00013S) • FOUNDATION Fieldbus Guideline • IEC 61158-2 (MBP) Current output 0/4 to 20 mA Standard installation cable is sufficient.
  • Page 15 Proline 300 FOUNDATION Fieldbus Electrical connection 5.1.3 Connecting cable for transmitter - remote display and operating module DKX001 Standard cable A standard cable can be used as the connecting cable. Standard cable 4 cores (2 pairs); pair-stranded with common shield Shielding Tin-plated copper-braid, optical cover ≥...

  • Page 16: Connecting The Measuring Device

    Electrical connection Proline 300 FOUNDATION Fieldbus 5.1.4 Terminal assignment Transmitter: supply voltage, input/outputs Supply voltage Input/output 1 Input/output 2 Input/output 3 1 (+) 2 (–) 26 (A) 27 (B) 24 (+) 25 (–) 22 (+) 23 (–) Device-specific terminal assignment: adhesive label in terminal cover.
  • Page 17 Proline 300 FOUNDATION Fieldbus Electrical connection 5.2.1 Connecting the transmitter A0026781 Cable entry for supply voltage Cable entry for signal transmission, input/output 1 and 2 Cable entry for input/output signal transmission; Optional: connection of external WLAN antenna, connection of remote display and operating module DKX001 or service plug –...
  • Page 18 Electrical connection Proline 300 FOUNDATION Fieldbus N ic N ic t e r t e r e r g ö f f e r g ö f f iz e iz e t e n t e n r ir...
  • Page 19 Proline 300 FOUNDATION Fieldbus Electrical connection 22 mm 24 mm – A0029816 10. Connect the cable in accordance with the terminal assignment .  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
  • Page 20 Electrical connection Proline 300 FOUNDATION Fieldbus Removing a cable 3 (0.12) A0029598  1 Engineering unit mm (in) To remove a cable from the terminal, use a flat-blade screwdriver to push the slot between the two terminal holes while simultaneously pulling the cable end out of the terminal.
  • Page 21 Proline 300 FOUNDATION Fieldbus Electrical connection 5.2.2 Connecting remote display and operating module DKX001 NOTICE Only one display or operation unit may be connected to the transmitter at any one time. The remote display and operating module DKX001 cannot be connected at the same time as the existing display and operating module.

  • Page 22: Ensuring Potential Equalization

    • Grounding rings can be ordered separately as an accessory from Endress+Hauser . When ordering make sure that the grounding rings are compatible with the material used for the...
  • Page 23 Proline 300 FOUNDATION Fieldbus Electrical connection Potential equalization via additional grounding ring A0028971 Hexagonal-headed bolts of process connection O-ring seals Plastic disk (spacer) or grounding ring Sensor Potential equalization via grounding electrodes on process connection A0028972 Hexagonal-headed bolts of process connection...
  • Page 24 Electrical connection Proline 300 FOUNDATION Fieldbus 5.3.2 Promag P For devices intended for use in hazardous locations, please observe the guidelines in the Ex documentation (XA). Metal, grounded pipe A0016315  2 Potential equalization via measuring tube Unlined and ungrounded metal pipe This connection method also applies in situations where: •...
  • Page 25 Proline 300 FOUNDATION Fieldbus Electrical connection Plastic pipe or pipe with insulating liner This connection method also applies in situations where: • The customary potential equalization is not used • Equalizing currents are present Ground cable Copper wire, at least 6 mm (0.0093 in...

  • Page 26: Ensuring The Degree Of Protection

    Electrical connection Proline 300 FOUNDATION Fieldbus Connect the measuring device to the power supply such that it is floating in relation to the protective ground (isolation transformer). Ensuring the degree of protection The measuring device fulfills all the requirements for the IP66/67 degree of protection, Type 4X enclosure.

  • Page 27: Operation Options

    Proline 300 FOUNDATION Fieldbus Operation options Operation options Overview of operation options A0029295 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...

  • Page 28: Structure And Function Of The Operating Menu

    Operation options Proline 300 FOUNDATION Fieldbus Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN  5 Schematic structure of the operating menu 6.2.2...

  • Page 29: Access To The Operating Menu Via The Local Display

    Proline 300 FOUNDATION Fieldbus Operation options Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language à English 20.50 Deutsch Español Français User ABC_ DEFG...
  • Page 30 Operation options Proline 300 FOUNDATION Fieldbus 6.3.1 Operational display Explanatory symbols for the measured value Status area • Depends on the device version, e.g.: The following symbols appear in the status area of the – : Volume flow operational display at the top right: –...
  • Page 31 Proline 300 FOUNDATION Fieldbus Operation options Numeric editor Confirms selection. Moves the input position one position to the left. Exits the input without applying the changes. Inserts decimal separator at the input position. Inserts minus sign at the input position.

  • Page 32: Access To The Operating Menu Via The Operating Tool

    Operation options Proline 300 FOUNDATION Fieldbus Keys and meaning Reduces the contrast (brighter setting). Plus/Enter key combination (press and hold down the keys simultaneously) Increases the contrast (darker setting). Minus/Plus/Enter key combination (press the keys simultaneously) For operational display:Enables or disables the keypad lock.

  • Page 33: System Integration

    Proline 300 FOUNDATION Fieldbus System integration System integration For detailed information on system integration, see the Operating Instructions for the device. Overview of device description files – Current version data for the device – Operating tools Cyclic data transmission Cyclic data transmission when using the device master file (GSD).
  • Page 34 System integration Proline 300 FOUNDATION Fieldbus 7.1.2 Assignment of the measured values in the function blocks The input value of a module/function block is defined via the CHANNEL parameter. AI module (Analog Input) Five Analog Input blocks are available. CHANNEL...
  • Page 35 Proline 300 FOUNDATION Fieldbus System integration Values Measured variable Value 6 Not assigned Value 7 Not assigned Value 8 Not assigned The external measured values must be transmitted to the device in the SI basic unit The selection is made via: Expert → Sensor → External compensation DI module (Discrete Input) Two Discrete Input blocks are available.
  • Page 36 System integration Proline 300 FOUNDATION Fieldbus CHANNEL Device function State Empty pipe detection 0 = off, 1 = active Verification status Overall result of the verification Verification: • 16 = Failed • 32 = Passed • 64 = Not performed...
  • Page 37 Proline 300 FOUNDATION Fieldbus System integration Value Device function State Value 1 Reset totalizer 1 0 = off, 1 = execute Value 2 Reset totalizer 2 0 = off, 1 = execute Value 3 Reset totalizer 3 0 = off, 1 = execute...
  • Page 38 System integration Proline 300 FOUNDATION Fieldbus Method Block Navigation Description Actual Diagnostic Via menu: This method is used to display diagnostics – Transducer Block – Configure/Setup → Diagnostics → remedial measures for the diagnostic Remedy Actual diagnostics event with the highest priority that is information –...

  • Page 39: Commissioning

    Proline 300 FOUNDATION Fieldbus Commissioning Commissioning Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist →  12 • "Post-connection check" checklist →  26 Setting the operating language...

  • Page 40: Configuring The Measuring Device

    Commissioning Proline 300 FOUNDATION Fieldbus Configuring the measuring device The Setup menu with its submenus and guided wizards is used for fast commissioning of the device. They contain all the parameters required for configuration, such as for measurement or communication.

  • Page 41: Diagnostic Information

    Proline 300 FOUNDATION Fieldbus Diagnostic information Diagnostic information Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. The message about remedial measures can be called up from the diagnostic message, and contains important information on the fault.
