Manual
WAGO-I/O-SYSTEM 750
2DO 125V AC 0.5A/ Relay 2CO/ Potential Free
753-514
2-Channel Relay Output Module 125 VAC, 30 VDC;
Isolated outputs; 2 changeover contacts
Version 1.1.0
Pos : 3 /Alle Serien (Allgemeine M odul e)/Hinweise z ur Dokumentation/Impres sum für Standardhandbüc her - allg. Angaben, Ansc hriften, Tel efonnummer n und E-Mail-Adres sen @ 3\mod_1219151118203_21.doc x @ 21060 @ @ 1
Advertisement
Chapters
Table of Contents
Related Manuals for WAGO 753-514
Summary of Contents for WAGO 753-514
- Page 1 Pos : 2 /D okumentati on allgemein/Ei nband/Ei nband H andbuch - Dec kbl att ohne Variantenfel d (Standar d) @ 9\mod_1285229289866_0.doc x @ 64941 @ @ 1 Manual WAGO-I/O-SYSTEM 750 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free 753-514 2-Channel Relay Output Module 125 VAC, 30 VDC;...
- Page 2 WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free © 2015 by WAGO Kontakttechnik GmbH & Co. KG All rights reserved. WAGO Kontakttechnik GmbH & Co. KG Hansastraße 27 D-32423 Minden Phone: +49 (0) 571/8 87 – 0 Fax: +49 (0) 571/8 87 –...
-
Page 3: Table Of Contents
WAGO-I/O-SYSTEM 750 Table of Contents 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 5 /D okumentati on allgemein/Verzeic hnisse/Inhalts verz eichnis - Ü berschrift oG und Verzei chnis @ 3\mod_1219151230875_21.doc x @ 21063 @ @ 1 Table of Contents Notes about this Documentation .............. - Page 4 Table of Contents WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free 6.2.1 1-Wire Connection, Protection Class I Actuators ......36 6.2.2 1-Wire Protection Class II and III Actuators ........36 Protective Circuits for Contacts of Relay Modules ......... 37 List of Figures ......................
-
Page 5: Notes About This Documentation
Validity of this Documentation Pos : 10 /Serie 750 ( WAGO-I/O-SYST EM)/Hi nweis e z ur D okumentati on/Gültigkeits bereic h/Gültig keits ber eich Dokumentation Bus kl emme 750- xxxx, ohne Variantenangabe @ 14\mod_1358944037947_21.doc x @ 109346 @ @ 1 This documentation is only applicable to the I/O module 753-514 (2DO 125V AC 0.5A/ Relay 2CO/ Potential Free). -
Page 6: Symbols
WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 12.3 /All e Seri en ( Allgemei ne Module)/Ü bers chriften für alle Serien/Hinweis e z ur Dokumentation/Symbol e - Ü bersc hrift 2 @ 13\mod_1351068042408_21.doc x @ 105270 @ 2 @ 1 Symbols Pos : 12.4.1 /All e Serien ( Allgemei ne Module)/Wic htige Erläuterungen/Sicherheits- und sons tige Hinweis e/Gefahr/Gefahr: _War nung vor Personenschäden allgemei n_ - Erl äuter ung @ 13\mod_1343309450020_21.doc x @ 101029 @ @ 1... - Page 7 WAGO-I/O-SYSTEM 750 Notes about this Documentation 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Additional Information: Refers to additional information which is not an integral part of this documentation (e.g., the Internet). Pos : 12.5 /Dokumentation allgemei n/Glieder ungs elemente/---Seitenwechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1 Manual Version 1.1.0...
-
Page 8: Number Notation
Notes about this Documentation WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 12.6 /All e Seri en ( Allgemei ne Module)/Hi nweis e zur D okumentati on/Zahlens ysteme @ 3\mod_1221059454015_21.doc x @ 21711 @ 2 @ 1... -
Page 9: Important Notes
PLC programming. Pos : 15.5 /Serie 750 (WAGO-I/O-SYST EM)/Wic htige Erläuterungen/Bes timmungsgemäß e Verwendung Bes ti mmungsgemäße Verwendung 750-xxxx - Ü berschrift 3 und Inhal t @ 3\mod_1224064151234_21.doc x @ 24070 @ 3 @ 1 2.1.3... -
Page 10: Technical Condition Of Specified Devices
Important Notes WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Appropriate housing (per 94/9/EG) is required when operating the WAGO-I/O- SYSTEM 750 in hazardous environments. Please note that a prototype test certificate must be obtained that confirms the correct installation of the system in a housing or switch cabinet. -
Page 11: Safety Advice (Precautions)
Pos : 15.10.2 /Serie 750 ( WAGO-I/O- SYST EM)/Wic htig e Erl äuter ung en/Sic her hei ts- und s onstige Hi nweise/Gefahr/Gefahr: Ei nbau 0750- xxxx nur i n Gehäus en, Sc hränken oder el ektrisc hen Betriebsräumen! @ 6\mod_1260180556692_21.doc... - Page 12 Important Notes WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Protect the components against materials having seeping and insulating properties! The components are not resistant to materials having seeping and insulating properties such as: aerosols, silicones and triglycerides (found in some hand creams).
-
Page 13: Device Description
The assignment of the connections is described in the “Connectors” section. Pos : 18.1.4 /Serie 750 (WAGO-I/O-SYST EM)/Gerätebesc hrei bung/Ei nlei tung/I/O-Besc hrei bung/Allgemein/Ver weis auf Kapi tel " Geräte anschli eß en" > "Ansc hlus sbeispi el(e)" @ 5\mod_1246015203281_21.doc x @ 36298 @ @ 1 Connection examples are shown in section “Connecting Devices”... - Page 14 Pos : 18.1.13 /Serie 750 ( WAGO-I/O- SYST EM)/Wic htig e Erl äuter ung en/Sic her hei ts- und s onstige Hi nweise/Ac htung/Ac htung: Maxi maler Str om Leis tungs kontakte 10 A @ 3\mod_1226499143500_21.doc...
-
Page 15: View
Figure 1: View Pos : 18.6 /Serie 753 (WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Ansic ht/Ansic ht – Leg ende mit 1LK, mit Kodier ung, Kabel befes tigung und Pr üföffnungen @ 22\mod_1425565508846_21.doc x @ 176967 @ @ 1 Table 3: Legend for Figure “View”... -
Page 16: Connectors
Pos : 18.10.2 /Serie 750 ( WAGO-I/O- SYST EM)/Wic htig e Erl äuter ung en/Sic her hei ts- und s onstige Hi nweise/Ac htung/Ac htung: Bus kl emmen nicht auf Gol dfeder kontakte l egen! @ 7\mod_1266318463636_21.doc... -
Page 17: Power Jumper Contacts/Field Supply
Pos : 18.13.1 /Serie 750 ( WAGO-I/O- SYST EM)/Wic htig e Erl äuter ung en/Sic her hei ts- und s onstige Hi nweise/Vorsicht/Vorsic ht: Verletzungsgefahr durc h sc har fkantige Mes ser kontakte! @ 6\mod_1256193279401_21.doc... -
Page 18: Cage Clamp ® Connectors
WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 18.15 /Serie 750 ( WAGO-I/O-SYST EM)/Gerätebeschr eibung/Ansc hlüss e/C AGE C LAMP-Ansc hlüsse - Ü bersc hrift 3 @ 6\mod_1256296337770_21.doc x @ 43674 @ 3 @ 1 ®... -
Page 19: Display Elements
Pos : 18.19 /Alle Serien (Allgemeine M odul e)/Übersc hriften für all e Seri en/Gerätebes chr eibung/Anzeigeel emente - Ü bersc hrift 2 @ 4\mod_1240984390875_21.doc x @ 31964 @ 2 @ 1 Display Elements Pos : 18.20 /Serie 750 ( WAGO-I/O-SYST EM)/Gerätebeschr eibung/Anzeig eel emente/Digitalausgangs klemmen/Anz eigeel emente 750- 05xx 2 DO CO (Agn, Cgn) @ 16\mod_1371808897994_21.doc x @ 123970 @ @ 1 Figure 5: Display Elements Table 6: Legend for Figure “Display Elements”... -
Page 20: Schematic Diagram
Pos : 18.22 /Alle Serien (Allgemeine M odul e)/Übersc hriften für all e Seri en/Gerätebes chr eibung/Sc hematisc hes Schaltbild - Übersc hrift 2 @ 4\mod_1240984441312_21.doc x @ 31967 @ 2 @ 1 Schematic Diagram Pos : 18.23 /Serie 753 ( WAGO-I/O-SYST EM)/Gerätebeschr eibung/Sc hematis ches Sc haltbild/Sc hematisches Sc haltbil d 753-0514 @ 22\mod_1425566170583_21.doc x @ 176981 @ @ 1 Figure 6: Schematic Diagram Pos : 18.24 /D okumentati on allgemei n/Gli ederungsel emente/---Seitenwec hs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1... -
Page 21: Technical Data
Pos : 18.26.2 /Serie 750 ( WAGO-I/O- SYST EM)/Wic htig e Erl äuter ung en/Sic her hei ts- und s onstige Hi nweise/Ac htung/Ac htung: Verlus t von Eigensc haften durc h hohe Schaltlei stung! @ 22\mod_1425462925724_21.doc... -
Page 22: Outputs
Pos : 18.26.5 /Serie 750 ( WAGO-I/O- SYST EM)/Gerätebeschr eibung/Tec hnische D aten/Kli matisc he U mwel tbedingungen/T ec hnis che D aten Kli mat. U mweltbed. ohne er w. Temp. 0...55°C/- 25...+ 85°C @ 5\mod_1247657968368_21.doc... -
Page 23: Load Limiting Value Graph Of The Relay
753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 18.26.7 /Serie 750 ( WAGO-I/O- SYST EM)/Gerätebeschr eibung/Tec hnische D aten/Digital ausgangs kl emmen/T ec hnische D aten 750-0514_Lastgrenz kur ve @ 18\mod_1395065141911_21.doc x @ 148092 @ 3 @ 1 3.5.7... -
Page 24: Approvals
750 > System Description. Pos : 18.30 /Serie 750 ( WAGO-I/O-SYST EM)/Gerätebeschr eibung/Zul ass ung en/Allgemein/Zul ass ung en Bus klemme 750- xxxx Allgemei n, ohne Vari antenangabe - Einlei tung @ 4\mod_1237460656921_21.doc x @ 28643 @ @ 1 The following approvals have been granted to 753-514 I/O modules: Pos : 18.31.1 /Alle Serien (Allgemeine D okumente) (Allgemeine M odul e)/Z ulass ungen/Standar dzul ass ungen/CE (Konfor mitäts kennz eic hnung) @ 3\mod_1224494777421_21.doc x @ 24276 @ @ 1... -
Page 25: Standards And Guidelines
Standards and Guidelines Pos : 18.38 /Serie 750 ( WAGO-I/O-SYST EM)/Gerätebeschr eibung/Nor men und Richtlinien/EMV-N or men Bus klemme 750- xxxx, ohne Variantenangabe - Ei nleitung @ 4\mod_1242803944015_21.doc x @ 33642 @ @ 1 753-514 I/O modules meet the following requirements on emission and immunity of interference: Pos : 18.39 /Alle Serien (Allgemeine M odul e)/Nor men und Ric htlini en/EM V-Nor men - Standard/EM V C E-Störauss endung EN 61000-6-4 @ 4\mod_1242798273984_21.doc x @ 33602 @ @ 1... -
Page 26: Process Image
Process Image Pos : 21 /Serie 750 ( WAGO-I/O-SYST EM)/Proz ess abbild Kl emmenbus /Hinweis: Prozes sabbildmapping abhängig von FBK/PFC, ohne Status-/Hinweis: Pr ozessabbildmapping abhängig von FBK/PFC, ohne Status-/C ontrol byte @ 6\mod_1256126797251_21.doc x @ 43340 @ @ 1 Mapping of process data in the process image of fieldbus systems The representation of the process data of some I/O modules or their variants in the process image depends on the fieldbus coupler/controller used. -
Page 27: Mounting
I/O modules with fewer power contacts. Pos : 25.2 /Serie 750 (WAGO-I/O-SYST EM)/Wic htige Erläuterungen/Sicherheits- und sonstig e Hinweis e/Vorsic ht/Vorsicht: Verl etz ungsgefahr durc h s charfkantige M ess er kontakte! @ 6\mod_1256193279401_21.doc x @ 43414 @ @ 1 Risk of injury due to sharp-edged blade contacts! The blade contacts are sharp-edged. -
Page 28: Inserting And Removing Devices
753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 25.6 /Serie 750 (WAGO-I/O-SYST EM)/M ontieren/D emontieren/Geräte einfüg en und entfer nen - Ü berschrift 2 @ 3\mod_1231768483250_21.doc x @ 25950 @ 2 @ 1 Inserting and Removing Devices Pos : 25.7 /All e Seri en ( Allgemei ne Module)/Wic htige Erläuterungen/Sicherheits- und sons tige Hi nweis e/Ac htung/Achtung: Arbeiten an Ger äten nur s pannungsfr ei durc hführ en! @ 6\mod_1256193963573_21.doc x @ 43426 @ @ 1... -
Page 29: Removing The I/O Module
WAGO-I/O-SYSTEM 750 Mounting 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 25.10 /Serie 753 ( WAGO-I/O-SYST EM)/Monti eren/Bus kl emme 753 entfernen @ 20\mod_1412665995998_21.doc x @ 165319 @ 3 @ 1 5.2.2 Removing the I/O Module Remove pluggable connector! Before removing a 753 Series I/O Module from the node, you must first remove the pluggable connector from the module (see section “Connector Removal”)! -
Page 30: I/O Modules With Pluggable Wiring Level (Series 753)
753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 25.12 /Serie 753 ( WAGO-I/O-SYST EM)/Monti eren/Bus kl emmen mi t stec kbarer Ver drahtungs ebene Serie 753 @ 3\mod_1232446676484_21.doc x @ 26262 @ 2 @ 1 I/O Modules with Pluggable Wiring Level (Series 753) Series 753 I/O modules feature a pluggable connector for I/O wiring. -
Page 31: Coding
WAGO-I/O-SYSTEM 750 Mounting 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 25.14 /Serie 753 ( WAGO-I/O-SYST EM)/Monti eren/Kodier ung der Stec ker Seri e 753 @ 4\mod_1240393983875_21.doc x @ 31217 @ 3 @ 1 5.3.1 Coding Coding using small plastic pins and sockets facilitates mating of the module with the appropriate connector. -
Page 32: Figure 17: "Sure Match" Coding Fingers
Mounting WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free When the connector is removed the sockets remain in the I/O module. The coded connector can only fit in the corresponding coded I/O module (see figures below). Figure 17: “Sure Match” Coding Fingers Pos : 25.15 /D okumentati on allgemei n/Gli ederungsel emente/---Seitenwec hs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1... -
Page 33: Connector Removal
Mounting 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 25.16 /Serie 753 ( WAGO-I/O-SYST EM)/Monti eren/Lös en des Stec kers von der Bus kl emme Serie 753 @ 4\mod_1240393485109_21.doc x @ 31214 @ 3 @ 1 5.3.2... -
Page 34: Connect Devices
Check if the voltage is positively isolated. Pos : 29 /Serie 750 ( WAGO-I/O-SYST EM)/Ans chli eßen/Leiter an C AGE C LAM P ans chli eßen ( allgemei n) - Übersc hrift 2 und Text @ 3\mod_1225448660171_21.doc x @ 24928 @ 2 @ 1 ®... -
Page 35: Figure 21: Connecting A Conductor To A Cage Clamp
WAGO-I/O-SYSTEM 750 Connect Devices 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free ® Figure 21: Connecting a Conductor to a CAGE CLAMP Pos : 30 /D okumentation allgemei n/Glieder ungs elemente/---Seitenwechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1 Manual Version 1.1.0... -
Page 36: Connection Examples
Pos : 31 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Ansc hließ en/Ans chl uss beis piel e - Ü berschrift 2 @ 4\mod_1240996036328_21.doc x @ 32010 @ 2 @ 1 Connection Examples Pos : 32 /Serie 753 ( WAGO-I/O-SYST EM)/Hi nweis e z ur D okumentati on/Hi nweis z um Z ubehörteil 753-110 @ 20\mod_1411023611789_21.doc x @ 163868 @ @ 1 Depiction of the I/O module with 753-110 Connector! Information on this pluggable connection pertains to the 753-110 Connector, which is not included with the I/O module. -
Page 37: Protective Circuits For Contacts Of Relay Modules
WAGO-I/O-SYSTEM 750 Connect Devices 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Protective Circuits for Contacts of Relay Modules Switching off inductive loads such as contactors and solenoid valves can generate transients with voltage peaks of up to several thousand volts. Very often, these transients exceed the permissible limits specified in the EMC standards. -
Page 38: Figure 28: R/C Combination
Connect Devices WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Table 16: Protective Circuits for Contacts of Relay Modules Protective Circuits Additional Defined Bipolar Advantages and Off-Delay Induction Effective Disadvantages Voltage Attenuation Limitation Advantages: • HF attenuation via power storage •... -
Page 39: List Of Figures
List of Figures 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 37 /D okumentation allgemei n/Verz eic hniss e/Abbil dungs verz eic hnis - Übersc hrift oG und Verz eichnis @ 3\mod_1219222916765_21.doc x @ 21080 @ @ 1 List of Figures Figure 1: View ....................... -
Page 40: List Of Tables
List of Tables WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 39 /D okumentation allgemei n/Verz eic hniss e/Tabell enverz eichnis - Übersc hrift oG und Verz eichnis @ 3\mod_1219222958703_21.doc x @ 21084 @ @ 1 List of Tables Table 1: Number Notation .................. - Page 41 WAGO-I/O-SYSTEM 750 753-514 2DO 125V AC 0.5A/ Relay 2CO/ Potential Free Pos : 41 /D okumentation allgemei n/Einband/Einband H andbuc h - Leers eite für durc h 2 teilbar e Seitenzahl (Standar ddr uc k) @ 3\mod_1219230851078_0.doc x @ 21123 @ @ 1 Manual Version 1.1.0...
- Page 42 Pos : 42 /D okumentation allgemei n/Einband/Einband H andbuc h - R üc kseite @ 9\mod_1285229376516_21.doc x @ 64944 @ @ 1 WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 • D-32385 Minden Hansastraße 27 • D-32423 Minden Phone: +49/5 71/8 87 – 0 Fax: +49/5 71/8 87 –...
