System Menu Set - Advantage Controls MicroTron Manual

This menu is used to configure the controller to specific
operational needs. All of the items in this menu may
not apply depending on the controller model but will
always be present.
NOTE: Do not use this menu to make calibration
adjustments. Use the Calibration screen.
PASSWORD - If a value of 0000 is entered, a
password is not required. If a password is
entered, it must be used to operate the controller.
If the first digit is zero, relays may be activated
without a password.
RESET WATER METER COUNT - Does not
apply unless the unit has selectable feed timer.
DRY CONTACT HEAD - Select a contacting head
water meter or a hall effect paddle wheel meter.
Anytime this setting is changed the GAL/PULSE
value will need to be re-entered.
GAL/PULSE - If a feed timer is using a contacting
head water meter this tracks make-up volume by
entering the number of gallons a contact equals.
Use • key to change to pulse/gal for flowmeter.
STRAIGHT/PROPORTIONAL OUTPUTS - A
straight output setting means the optional 4-20
output span will be the same as the full scale.
The proportional setting allows the span of the
4-20 mA output to be selected by the user based
on the setpoint and differential.
LOW DRUM NO PUMP/PUMP LOW DRUMS - If
unit has low level alarms, allows the associated
feed timer to be forced off when drum is low.
COMM Setup:
BAUD RATE - For units ordered with the serial
line or modem option.
ALARM CALL - For units with modem.
FLOW WHEN CLOSED - For flow switches.
PASSWORD XXXX
ENTER
RESET METER
ENTER
DRY CONTACT HEAD
ENTER
ENGLISH UNITS
ENTER
GAL/PULSE
ENTER
BLEED/PULSE
ENTER
STRAIGHT OUTPUTS
ENTER
PUMP LOW DRUMS
ENTER
BAUD RATE 1200
ENTER
System Set continued on next page.
17
-- SYSTEM SET --
Numeric keys to set
password
Count zeroed
To change to HALL EFFECT
METRIC UNITS
Numeric keys to change
gal/pulse
Numeric keys to change
gal/pulse for bleed
To change to PROPORTIONAL
OUT
To change LOW DRUM/ NO
PUMP
To change baud rate
