7

MultiGasAnalyser OR-703

7.1

Description

7.2

Use

7.3

Warning

IMT Analytics AG
MultiGasAnalyser OR-703 consists of a 10-channel infrared (NDIR) gas sensor, a
barometric pressure sensor, a CPU and an RS-232 Interface.
This User Manual describes the specifications of the red model of MultiGasAnalyser
OR-703. If you have any questions about the blue model, please contact our Tech-
nical Support.
The sensor can measure the following gas concentrations:
• Carbon dioxide (CO )
2
• Nitrogen oxide (N O)
2
• Halothane (HAL)
• Enflurane (ENF)
• Isoflurane (ISO)
• Sevoflurane (SEV)
• Desflurane (DES)
The concentrations of CO , N
2
ured at the same time.
MultiGasAnalyser OR-703 is designed to perform, in conjunction with FlowAnalyser,
to perform gas measurements for the calibration and testing of anaesthesia systems
and facilities.
The sensor is not suitable for monitoring patients.
The sensor is not suitable in conjunction with applications that are parts of means of
transport such as cars or aircraft.
MultiGasAnalyser OR-703 may only be used by professionally trained
personnel.
MultiGasAnalyser OR-703 may not be used with flammable anaes-
thetic agents.
Used airway adapters that have to be discarded must be disposed
of in accordance with local waste disposal regulations for biologically
contaminated liquids.
Measurements can be detrimentally affected by RF radiation, e.g., by
cellphone communication.
Care must be taken to ensure that MultiGasAnalyser is only operated
in an EMC-specified environment.
MultiGasAnalyser OR-703
O and two of the five anaesthetic gases can be meas-
2
