Numerical display

IMT Analytics AG
When the device has been switched on, the Numerical 1 display appears. This
display can show four measurement parameters simultaneously. The title bar also
shows the currently set gas type, standard, battery charge status, mains operation
and USB connection.
1 2 3
8
10
9
11 12
6.6.1 Specification of the numerical display
1
Number of the numerical display. In total there are four different numerical
displays so up to 16 values can be shown.
2
Trigger signal. This icon indicates when a trigger event occurs during the
ventilation currently being measured. This means that the time of appearance
of the indicator is identified as the start of inspiration. The indicator appears
for ½ second. If this signal does not occur during ventilation, the triggers must
be adjusted for the current ventilation mode
trigger event has occurred "No Tr" is displayed instead of the reading.
3
Base flow. This icon appears if the base flow function has been enabled for
volume measurement (6.14 Set
4
Currently selected gas type. The gas type being measured must be set on the
device accordingly (6.13 Gas type and
5
Standard. The readings displayed are converted to the standard indicated. It
is possible to select from multiple current gas standards
standards).
6
Power supply. This icon appears if the device is connected to the power
supply. The measuring instrument can also be operated with the integrated
battery. This icon appears if the device is being operated from the battery. The
icon varies according to the charge status:
Battery full
Battery flat – please charge!
An audible warning will be heard if the battery is very low
ation).
7
USB. The measuring instrument can be connected to the PC using the USB
port. The icon appears as soon as a connection to the PC has been estab-
lished.
8
Measurement parameter. Indicates the measurement parameter currently
selected. Measurement parameters can be changed in configuration
Specification of the configuration
4 5 6 6 7
13 14
(6.14 Set trigger). As long as no
trigger).
standard).
(6.13 Gas type and
display).
Operation
6
(4.4 Battery oper-
(6.7.1
