1

Introduction

This document defines EM05 module and describes its air interface and hardware interfaces which are
connected with customers' applications.
This document can help customers to quickly understand the interface specifications, electrical and
mechanical details, as well as other related information of EM05 module. To facilitate its application in
different fields, reference design is also provided for customers' reference. Associated with application
note and user guide, customers can use the module to design and set up mobile applications easily.
