Quectel EM05 Hardware Design page 19

53 N/C
54 N/C
55 N/C
56 N/C
57 GND
58 N/C
59 ANTCTL0
60 COEX3
61 ANTCTL1
62 COEX2
63 ANTCTL2
64 COEX1
65 ANTCTL3
66 SIM_DETECT
67 RESET#
68 SUSCLK (32kHz)
69 CONFIG_1
70 3.3V
71 GND
72 3.3V
73 GND
74 3.3V
75 CONFIG_2
EM05_Hardware_Design
NC
NC
NC
NC
GND
NC
RESERVED
NC
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
USIM_DET DI
RESET# DI
NC
CONFIG_1
VCC PI
GND
VCC PI
GND
VCC PI
CONFIG_2
Confidential / Released
NC
NC
NC
NC
Ground
NC
Reserved
NC
Reserved
Reserved
Reserved
Reserved
Reserved
(U)SIM card insertion detection
Reset the module. Active low.
NC
Connected to GND internally.
EM05 is configured as
WWAN-SSIC-0.
Power supply
Ground
Power supply
Ground
Power supply
Connected to GND internally.
EM05 is configured as
WWAN-SSIC-0.
LTE Module Series
EM05 Hardware Design
1.8V
1.8V
3.135V~4.4V
3.135V~4.4V
3.135V~4.4V
18 / 59
