Product Concept

2.1. General Description

EM05 is a series of LTE/UMTS/HSPA+ wireless communication module with receive diversity. It provides
data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA, WCDMA and CDMA
networks. It also provides optional GNSS functionality to meet customers' specific application demands.
EM05 contains three variants: EM05-CE, EM05-CML and EM05-E*. Customers can select a dedicated
type based on the region or operator. The following table shows the frequency bands of EM05 series
module.
Table 1: Frequency Bands of EM05 Series Module
Modules LTE Bands
FDD: B1/B3/B5/B8
EM05-CE
TDD: B38/B39/B40/B41
EM05-CML TDD: B38/B39/B40/B41
FDD: B1/B3/B7/B8/B20/B28
EM05-E*
TDD: B38
EM05 can be applied in the following fields:

Rugged Tablet PC and Laptop Computer

Remote Monitor System

Handheld mobile device

Wireless POS System

Smart Metering System

Other Wireless Terminal Devices
EM05_Hardware_Design
WCDMA CDMA
Bands Band
WCDMA:
BC0
B1/B8
/ /
WCDMA:
/
B1/B8
Confidential / Released
LTE Module Series
EM05 Hardware Design
GNSS
Rx-diversity
(Optional)
Supported
GPS,
GLONASS,
Supported
BeiDou,
Galileo,
QZSS
Supported
