1 Door Storage Cabinet
Assembly Instructions
011 xx 9435
- Please keep for future reference
Dimensions
Width - 42.0cm
Depth - 35.0cm
Height - 79.0cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 20/06/19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JD Williams 011 9435 Series
Summary of Contents for JD Williams 011 9435 Series
- Page 1 1 Door Storage Cabinet Assembly Instructions 011 xx 9435 - Please keep for future reference Dimensions Width - 42.0cm Depth - 35.0cm Height - 79.0cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 1491 1493 Shelf x 3 (39x34.8cm) Door Panel (36.6x38.4cm) 1492 1494 End Panel x 2 Back Panel (79x35cm) (78.5x41.6cm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some cases more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 1491 1494 1492 1491 1492 1491 1493... - Page 6 Assembly Instructions Step 1 Correct Attach hinges and handles to the doors Incorrect Insert hinges into holes, ensure the hinge is straight (90 degree angle). 1493 Bradawl Before securing the hinges , we recommend you pre - mark the doors using a bradawl.
- Page 7 Assembly Instructions Step 2 Fitting door stop on the shelf panel. Insert plastic door stop 1491 into one of the shelf panels as shown. 1491 Step 3 Secure shelf panels to end panel. Panel with door stop Locate screws through 1492 holes in end panel 1491...
- Page 8 Assembly Instructions Step 5 Squaring up the unit. DIAG 2 DIAG 1 DIAG 3 IMPORTANT! Ensure a tape measure is used to square unit up. Before securing the back it is necessary to square up the unit. You can do this by measuring between XX - XX and YY - YY ensuring these are the...
- Page 9 Assembly Instructions Step 7 1492 Fitting hinge plates to the end panel. Attach hinge plates the end panel 1492 shown Please note that the doors can be hung at either side of the unit. Step 8 Hanging doors With help, slot door hinges onto hinge plates.
- Page 10 Assembly Instructions Step 9 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 11 Assembly Instructions Step 10 WARNING Fixing to wall We recommend that this IN ORDER TO PREVENT OVERTURNING THIS PRODUCT MUST BE USED WITH unit is fixed to a suitable THE WALL ATTACHMENT DEVICE wall to prevent possible PROVIDED overbalancing. We have Serious or fatal crushing injuries can occur from included a fixing bracket furniture tipping over.
- Page 12 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
