4 Drawer Chest
002 xx 6641
- Please keep for future reference
Dimensions
Width - 66.8cm
Depth - 35.2cm
Height - 72.4cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev B - 01/02/2017
