3 Drawer Chest
Assembly Instructions
002 xx 6651
- Please keep for future reference
Dimensions
Width - 66.8cm
Depth - 33.0cm
Height - 59.2cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev C - 03/10/2016
Advertisement
Related Manuals for JD Williams OSLO 3 DRAWER
Summary of Contents for JD Williams OSLO 3 DRAWER
- Page 1 3 Drawer Chest Assembly Instructions 002 xx 6651 - Please keep for future reference Dimensions Width - 66.8cm Depth - 33.0cm Height - 59.2cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 622xx7002 Left drawer side x 3 (30x10cm) 5516 (66.8x33.0cm) 0266 0267 623xx7002 Left End Panel Right End Panel 8553 Right drawer side x 3 Plinth (57.7x32.8m) (57.7x32.8cm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 5516 0266 9200 0268 0267 8553 622xx7002 624xx7010 5671 0155 623xx7002 Drawers x3... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 4 metal dowels into the top panel 5516 5516 Note: Tighten metal dowels up fully against the panel. Do not over-tighten. Step 2 Fitting cams to the plinth and bottom panels.
- Page 7 Assembly Instructions Step 4 Front of Runner Attaching runners to the end panels. Position the runner so that the second hole from the front of the runner lines up with the pre-drilled hole nearest to the edge of the panel. 0266 Use screws to secure...
- Page 8 Assembly Instructions Insert 2 metal dowels into the the drawer fronts 0155 0155 622xx7002 Slide drawer bottom 624xx7010 into grooves in the left and right drawer sides and the drawer back. 5671 SLIDE! Foil surface facing upwards. 623xx7002 Plain chipboard surface to underside.
- Page 9 Assembly Instructions Step 7 0266 Connect left end to the plinth and bottom panels. Connect the dowels in the left end 0266 to the cams in the plinth panel 8553 and bottom panel 0268 0268 Turn cams 180 degrees to lock.
- Page 10 Assembly Instructions Step 10 Squaring up the unit. DIAG 2 DIAG 1 DIAG 3 IMPORTANT! Ensure a tape measure is used to square unit up. Before securing the back it is necessary to square up the unit. You can do this by measuring between XX - XX and YY - YY ensuring these are the...
- Page 11 Assembly Instructions Step 12 Fit the drawers. Stand the unit up. For this step we recommend you follow 2nd Hole the helpful hints on the next page.
- Page 12 Assembly Instructions Step 13 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer closed.The screwdriver will push against the end 2nd Hole panel and extend the...
- Page 13 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
