3 Door Mirrored Robe
Assembly Instructions
001 xx 4048
- Please keep for future reference
Dimensions
Width - 100.2cm
Depth - 49.8cm
Height - 179.9cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 07/06/2017
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JD Williams 001 4048 Series
Summary of Contents for JD Williams 001 4048 Series
- Page 1 3 Door Mirrored Robe Assembly Instructions 001 xx 4048 - Please keep for future reference Dimensions Width - 100.2cm Depth - 49.8cm Height - 179.9cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 9371 (100.2x49.8cm) 9372 Bottom (96.8x45.8cm) 9375 Plinth x 2 (96.8x9.2cm) 9373 9367 9368 Divider (167.5x46.0cm) Left End Panel Right End Panel 9374 Back Rail (96.8x12.4cm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 7194 9371 9200 9367 9377 9366 9373 9368 9376 9374 9369 9369 9369 9372 9375... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 6 metal dowels into the top panel 9371 Note: Tighten metal 9371 dowels up fully against the panel. Do not over-tighten. Step 2 Connect the top rail to the top panel. 7200 Using 4 screws secure...
- Page 7 Assembly Instructions Correct Step 5 Attach hinges to the 3 doors Incorrect Insert hinges into holes, ensure the hinge is straight (90 degree angle). 9369 Before securing the Bradawl hinges , we recommend you pre - mark the doors using a bradawl. 9369 Secure hinges doors using screws...
- Page 8 Assembly Instructions Step 6 Fitting hanging rail support & hingeplates to left end. Insert 3 hinge plates into the left end panel 9367 Insert 2 screws through the holes in the hanging rail support Note: A bradawl may be 9367 required when attaching the hanging rail support to create the lower hole.
- Page 9 Assembly Instructions Step 8 Fitting cams & dowels to the left end panel. Insert 10 metal dowels and 2 cams into 9367 left end panel 9367 Step 9 Fitting cams & dowels to the right end panel. Insert 10 metal dowels and 2 cams into 9368...
- Page 10 Assembly Instructions Step 11 Attach haing rail support and cams to the divider panel. Insert 2 metal cams into the divider panel 9373 9373 Secure the hanging rail support bracket with 2 screws Step 12 Attach dowels and hinge plates. Insert 2 metal dowels and 3 hingeplates into the divider panel...
- Page 11 Assembly Instructions Step 14 Connect the right end panel to the bottom, and small shelf. Connect the dowels in 9368 9368 the right end panel to the cams in the bottom 9372 and the small shelf 9376 9376 Turn cams 180 degrees clockwise to lock.
- Page 12 Assembly Instructions Step 17 Connect the right end panel to the plinths and back rail. Connect the large shelf to the divider. Connect the dowels in the divider panel 9373 9366 9368 to the cams in the large shelf panel 9366 9373 Connect the dowels in...
- Page 13 Assembly Instructions Step 19 Connect the top panel to the divider and the end panels. Connect the dowels in the 9371 top panel to the cams in the left end 9367 9373 , divider 9371 the right end panel 9368 9368 9373 9367...
- Page 14 Assembly Instructions Step 21 Squaring up the unit. IMPORTANT! Ensure a tape measure is used 9143 to square unit up. 8588 Before securing the back it is necessary to square up the unit. Make sure that the back panel is still sat in the grooves.
- Page 15 Assembly Instructions Step 23 Add stability blocks. Slide the thin point of the stability blocks between the back panel 9377 and the grooves. Once inserted fully, tighten the screws in the stability blocks. 9143 9377 8588 8589...
- Page 16 Assembly Instructions Step 24 IMPORTANT! Fixing to wall We recommend that this This unit must be secured to the unit is fixed to a suitable wall prior to fitting the doors. wall to prevent possible overbalancing. We have Failure to do this could make the unit included a fixing bracket unstable and potentially dangerous for this.
- Page 17 Assembly Instructions Step 26 Hanging doors With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. Tighten screw shown to lock hinges in position. See ‘Hinge adjustment’ page if the doors need adjusting.
- Page 18 Assembly Instructions Step 27 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 19 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
