2 Drawer Filing Cabinet
Assembly Instructions
023 xx 9433
- Please keep for future reference
Dimensions
Width - 47.2cm
Depth - 38.8cm
Height - 56.1cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A- 22/05/19
Advertisement
Related Manuals for JD Williams 023 9433 Series
Summary of Contents for JD Williams 023 9433 Series
- Page 1 2 Drawer Filing Cabinet Assembly Instructions 023 xx 9433 - Please keep for future reference Dimensions Width - 47.2cm Depth - 38.8cm Height - 56.1cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 622xx7002 Left drawer side (30.0x10.0cm) 1390 (47.2x38.8cm) 1391 1392 623xx7002 Left End Panel Right End Panel 1394 Right drawer side Plinth (54.6x35.5m) (54.6x35.5 cm) (30.0x10.0cm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 1390 1397 1391 1392 1393 622xx7002 624xx7008 1394 623xx7002 8079 1396 624xx7009 622xx7004 623xx7004 7622 1395... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 4 metal dowels into the top panel 1390 1390 Note: Tighten metal dowels up fully against the panel. Do not over-tighten. Step 2 Fitting wooden dowels to the plinth panels. Insert 4 wooden dowels into the plinth panel 1394...
- Page 7 Assembly Instructions Step 4 Diagram 1 Attaching the left bracket to the left end. Using 2 screws secure the bracket the left end panel 1391 as shown in diagram 1. Diagram 2 1391 Use 1 screw secure the front of the bracket.
- Page 8 Assembly Instructions Step 7 Drawer assembly Insert dowels into 1396 1396 drawer front . Note: Insert metal dowels as far as shown by arrows. 1395 Repeat on Do not over tighten. Right hand side 623xx7002 Insert small cams 622xx7002 into left and right 623xx7002 drawer sides.
- Page 9 Assembly Instructions Step 7 - Continued Drawer assembly Continued... Slide drawer bottom 8079 8079 into grooves in left,right drawer sides FOIL FACE and drawer back. Ensure foil on the drawer bottom is facing upwards. : Insert cams already inserted in left and right drawer sides onto dowels in drawer...
- Page 10 Assembly Instructions Step 8 Connect left end to the bottom and plinth panel Connect the dowels in 1391 the left end 1391 to the cams in the bottom panel 1393 and the wooden dowels in the plinth panel 1394 Ensure plinth sits Ensure plinth is 1393 flush.
- Page 11 Assembly Instructions Step 11 Slide back panel into DIAG 2 DIAG 1 DIAG 3 grooves and Squaring up the unit. Slide the back panel into the grooves in the end panels and top panel. IMPORTANT! Ensure a tape measure is used to square unit up.
- Page 12 Assembly Instructions Step 13 Add stability blocks. Slide the thin point of the stability blocks between the back panel 1397 and the grooves. 1397 Once inserted fully, tighten the screws in the stability blocks. IMPORTANT! Please ensure that the stability blocks are used correctly to secure the back panel in place.
- Page 13 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
