2 Door 1 Drawer Cupboard
Assembly Instructions
044 xx 9432
- Please keep for future reference
Dimensions
Width - 70.0cm
Depth - 36.8cm
Height - 74.7cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 15/05/2019
Advertisement
Related Manuals for JD Williams 0449432 Series
Summary of Contents for JD Williams 0449432 Series
- Page 1 2 Door 1 Drawer Cupboard Assembly Instructions 044 xx 9432 - Please keep for future reference Dimensions Width - 70.0cm Depth - 36.8cm Height - 74.7cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 1344 2344 Bottom (70x36.8cm) (66.6x33.5cm) 2348 1343 Plinth 1339 (66.6x6cm) Left End Panel Right End Panel (73.2x35cm) (73.2x35cm) 2350 Backpanel 2347 Shelf (67.6x67.2cm) (66.6x29.7cm)
- Page 4 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View Please check you have all the fittings listed below 1344 1343 1451 1341 2350 2347 2349 1339 2344 1340 622xx7002 624xx7003 4883 623xx7002 1342... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. 1344 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fitting cams to the bottom and shelf panels. 2344 2347 Note: Ensure cam arrow points towards the edge with hole.
- Page 7 Assembly Instructions Step 4 Fitting cams to divider and rail panels and fitting dowels to the 2348 plinth panel. 1341 Insert 2 cams into the divider and 2 cams 1341 into the rail 1451 1451 Insert 4 wooden dowels into the pre- drilled holes in the end of the plinth panel 2348...
- Page 8 Assembly Instructions Step 7 Attach hinges and handles to doors Important: Insert hinges into holes, ensure the hinge is straight (90 degree angle). 2349 2349 Before securing the hinges , we recommend you pre - mark the doors using a bradawl. Bradawl 2349 Secure hinges...
- Page 9 Assembly Instructions Step 8 Drawer assembly Insert dowels into 1342 1342 drawer front . Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Right hand side 623xx7002 Insert small cams 622xx7002 into left and right 623xx7002 drawer sides.
- Page 10 Assembly Instructions Step 8 - Continued Drawer assembly Continued... Slide drawer bottom 4883 4883 into grooves in left,right drawer sides FOIL FACE and drawer back. Ensure foil on the drawer bottom is facing upwards. : Insert cams already inserted in left and right drawer sides onto dowels in drawer...
- Page 11 Assembly Instructions Step 9 Connect top panel to divider panel. Insert the dowels in the 1341 top panel 1344 into cams 1341 in the divider panel 1344 Step 10 Connect rail to right hand end. 1451 Insert the dowels in the 1339 right end panel the cams in the rail...
- Page 12 Assembly Instructions Step 12 Attach right end panel Insert the dowels in the 1339 right end panel into 2348 the cams in the shelf 2347 2344 and bottom panel and the plinth 2348 2347 2344 1339 Step 13 Attach the top panel. 1341 Connect the dowels in the top panel...
- Page 13 Assembly Instructions Step 14 Squaring up the unit. DIAG 2 DIAG 1 DIAG 3 Important: Ensure a tape measure is used to square up unit! Before securing the back it is necessary to square up the unit. You can do this by measuring between XX - XX and YY - YY ensuring these are the...
- Page 14 Assembly Instructions Step 16 Hanging doors With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. 2349 Tighten screw shown to lock hinges in position. See ‘Hinge adjustment’ page if the doors need adjusting.
- Page 15 Assembly Instructions Step 16 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 16 Assembly Instructions Step 17 Fit the drawer. Tilt the drawer as shown and slide onto the runner brackets.
- Page 17 Assembly Instructions Step 19 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
- Page 18 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
- Page 19 Notes;...
- Page 20 Notes;...
