3 Door 1 Drawer Robe

Assembly Instructions

001 xx 4506

- Please keep for future reference

Dimensions

Width - 101.5cm

Depth - 50.0cm

Height - 179.9cm

MADE IN

GREAT BRITAIN

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123

Please turn to back page for important information when contacting Customer Helpline.

Rev E - 15/11/2017

Need help?

Do you have a question about the 001 4506 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for JD Williams 001 4506 Series

Page 1 3 Door 1 Drawer Robe Assembly Instructions 001 xx 4506 - Please keep for future reference Dimensions Width - 101.5cm Depth - 50.0cm Height - 179.9cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 9482 (101.5x50.0cm) 9483 Bottom (95.0x46.7cm) 9148 Plinth (95.0x7.6cm) 9486 9138 9484 9485 Divider Large Door Left End Panel Right End Panel (169.1x46.7cm) (170.0x31.3cm) 4899...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
Page 5: Exploded View
Exploded View 7194 684xx6528 9482 9484 9147 9488 9486 9479 9487 9485 4899 9138 9489 9481 9483 (7010 if white) 622xx4504 624xx7010 9148 684xx6528 9475 (8027 if white) 8552 623xx4504 (7010 if white)
Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 6 metal dowels into the top panel 9482 Note: Tighten metal 9482 dowels up fully against the panel. Do not over-tighten. Step 2 9488 Connect the top rail to the top panel. Using 4 screws secure 9488...
Page 7 Assembly Instructions Step 5 Fitting hanging rail support & hingeplates to left end. Insert 3 hinge plates into the left end panel 9484 Insert 2 screws through the holes in the hanging rail support Note: A bradawl may be required when attaching the hanging rail support 9484 to create the lower hole.
Page 8 Assembly Instructions Step 7 Attaching runners to the end panels. Position the runner so that the second hole from the front of the runner lines up with the 9484 pre-drilled hole nearest to the edge of the panel. Use screws to secure the runner.
Page 9 Assembly Instructions Step 9 Fitting cams & dowels to the right end panel. Insert 6 metal dowels and 2 cams into 9485 right end panel 9485 Step 10 Fitting cams to the shelf. Insert 4 cams into the 9481 shelf panel 9481 Step 11 Fitting hanging rail...
Page 10 Assembly Instructions Step 12 TURN PANEL OVER. Fitting hanging rail support & hingeplates to right end. Take care and ensure that the fittings in the reverse face do not damage the floor. 9486 Insert 3 hinge plates and 4 metal dowels into the divider panel 9486 Insert 2 screws...
Page 11 Assembly Instructions Step 15 Correct Attach hinges to the doors Insert hinges into holes, ensure the hinge is straight (90 degree angle). 9138 Before securing the Bradawl hinges , we recommend you pre - mark the doors using a bradawl. 9138 Secure hinges doors using screws...
Page 12 Assembly Instructions Step 16 Insert small cams 622xx4504 into left and right 623xx4504 Right hand side drawer sides. (7010 if white) 623xx4504 Note: Ensure cam arrow points towards the edge with hole. Left hand side 622xx4504 (7010 if white) Insert wooden dowels in drawer back 624xx7010 into holes in...
Page 13 Assembly Instructions (7010 if white) 622xx4504 Slide drawer bottom 624xx7010 into grooves in the left and right drawer sides and the drawer back. 9475 SLIDE! (8027 if white) Foil surface facing upwards. 623xx4504 Plain chipboard surface (7010 if white) to underside. : Locate the metal dowels (already inserted) 624xx7010...
Page 14 Assembly Instructions Step 18 9489 Connect the right end panel to the bottom, and small back rail. Connect the dowels in 9485 the right end panel 9485 to the cams in the bottom 9483 and small back rail 9489 Turn cams 180 degrees clockwise to lock.
Page 15 Assembly Instructions Step 21 Connect the right end panel to the plinth. Connectthe large shelf and large back rail to the divider panel Connect the dowels in the divider panel 9486 to the cams in the shelf 9481 and the large back 9485 4899 rail...
Page 16 Assembly Instructions Step 23 Connect the top panel to the divider and the end panels. 9482 Connect the dowels in the 9485 9482 top panel to the cams in the left end 9484 9486 , divider the right end panel 9485 9486 9484...
Page 17 Assembly Instructions Step 25 Squaring up the unit. IMPORTANT! Ensure a tape measure is used to square unit up. 9143 Before securing the back 8588 it is necessary to square up the unit. Make sure that the back panel is still sat in the grooves.
Page 18 Assembly Instructions Step 27 Add stability blocks. Slide the thin point of the stability blocks between the back panel 9147 and the grooves. Once inserted fully, tighten the screws in the stability blocks. Stand the unit up after the stability blocks have been added - 2 people will be required for this step.
Page 19 Assembly Instructions Step 28 Hanging doors With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. 9479 Tighten screw shown to lock hinges in position. 9138 See ‘Hinge adjustment’...
Page 20 Assembly Instructions Step 29 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
Page 21 Assembly Instructions Step 30 Fit the drawers. For this step we recommend you follow the helpful hints on the next page. 2nd Hole...
Page 22 Assembly Instructions Step 31 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer in until the screwdriver pushes against the 2nd Hole panel.
Page 23 Assembly Instructions Step 32 The doors have been removed only for illustration purposes. Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of...
Page 24 Assembly Instructions Step 34 Attaching the trims Turn unit over. Locate the notch on trim into groove on left 9484 and right 9485 ends. 9484 Ensure the trims are positioned correctly. To insert trims use a hammer, place a cardboard packing piece between the hammer and trims to protect the trims.
Page 25 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
