9.
Drill four (4) 5/16"
diameter clearance holes,
per mating units, through
the back assemblies as
shown.
10.
Secure using bolts,
washers and nuts as
shown. Bolt may be
inserted from either side.
11.
Repeat steps 1
through 8 if more base units
are required.
12.
Remove clamps and
add canopy dust covers
where appropriate.
APPROX.
APPROX.
20"
APPROX.
12"
DRILL 5/16"
DIAMETER
CLEARANCE
HOLES
APPROX.
20"
20"
9
10
