Back Assembly - Steelcase Opus Conference Table Assembly Instructions Manual

®
NOTE: 24" Base Assembly
shown.
1.
Lay back assembly
onto two (2) padded saw
horses. Insert pins and
wood dowels into the
holes of the back
assembly as shown (1a).
Before installing the wood
dowel, wet the dowel with
a wet sponge to activate
the adhesive on the
surface of the dowel (1b).
NOTE: Make sure the
arrow located on each
cam is pointed toward the
hole that will accept the
pin.
1b
CAM
PIN
1a
WOOD
DOWEL

BACK ASSEMBLY

PADDED SAWHORSE
Page 2 of 15
939500267 Rev H
