- Page 1 Hodedah www.hodedah.com support @hodedah.com HI 917N L17'' X D15 '' X H19...
- Page 2 Hodedah www.hodedah.com support @hodedah.com PART & HARDWARE LIST PVC LEG STUD (LEFT & RIGHT) PLASTIC DOWEL M8 X 25MM MINIFIX 5654 CB SCREW M3.5 X 12MM CB SCREW M4 X 25MM HANDLE 2838 (PVC) CB SCREW M4 X 35MM CSK CAP M6 X 40MM...
- Page 3 Hodedah www.hodedah.com support @hodedah.com - This product contains small components, please ensure that they are kept away from small children. - THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. DO NOT RETURN PRODUCT TO THE STORE.
-
Page 4: Helpful Hints
- Never push, drag or pull your furniture (especially on carpet). Warranty Information Hodedah warrants this product to be free from defects in material and workmanship agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to be repair or replacement of defective parts and no assembly labor is included. -
Page 5: Left View
Hodedah www.hodedah.com support @hodedah.com STEP 1 CB SCREW M4 X 25MM PLASTIC DOWEL M8 X 25MM CB SCREW M3.5 X 12MM DRAWER SLIDE 14" LEFT VIEW RIGHT VIEW - Insert 16 x Plastic dowel (A) into Panels (1), (2) (3), (4), (5) & (6) using a plastic hammer. - Page 6 Hodedah www.hodedah.com support @hodedah.com STEP 2 CB SCREW M4 X 35MM HANDLE 2838 (PVC) P/H SCREW M4 X 36MM POWER NAIL " - Attach 2 x Panel (11) into Panel (9). Then, attach 1 x Panel (10) into both Panel (11) & insert 8 x CB Screw M4 x 35mm (D) using a Philips head screwdriver.
-
Page 7: Bottom View
Hodedah www.hodedah.com support @hodedah.com STEP 3 MINIFIX 5654 CB SCREW M3.5 X 12MM CSK CAP M6 X 40MM ALLEN KEY DRAWER SLIDE 14" BOTTOM VIEW - Assemble 2 x Drawer slide (L2) to both Panel (11) with 6 x CB Screw M3.5 x 12m (C) using Philips head screwdriver. - Page 8 Hodedah www.hodedah.com support @hodedah.com STEP 4 PVC LEG STUD (L&R) CB SCREW M3.5 X 12MM MINIFIX 5654 CSK CAP M6 X 40MM ALLEN KEY - Attach Panel (6) into Panel (2), (3), (4) & (5) with 2 x CSK Cap M6 x 40mm (E) & tighten with Allen Key (G).
-
Page 9: Back View
Hodedah www.hodedah.com support @hodedah.com STEP 5 POWER NAIL " BACK VIEW - Fix 1 x Panel (8) into the back of Night Stand & use 20 x Power nail (F) for fix it. Knock by using a hammer. - Slide the drawer box into the drawer slide at the Panel (1) & (6).
