Hand Crimp Tool for Ring Tongue Terminal
Tool Kit
Order No. 63827-1170
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
%
Ergonomically designed soft handles
%
Precisely designed crimping profiles with simple contact positioning
%
Easy handling due to outstanding force ratio
%
Tool kits are easily installed into the Hand Crimp Tool or the 63816-0300 Power Crimp Head which is installed
into the 63816-0200 (110 V) or the 63816-0250 (220 V) Battery Powered Tool.
Many different Tool kits can be used with a single Battery Powered Tool.
This tool is IPC/WHMA-A-620 Class 2 as indicated, and RoHS compliant.
SCOPE
Products: Ring Tongue Terminal for 14-24 AWG Wire (1.50 - 0.50mm²), Metal Strip.
Terminal
Terminal Order No.
Series No.
Reel form only (3)
94511-1310 94511-1311
94511-1410 94511-1411
94511
94511-1520 94511-1521
94511-1610 94511-1611
(1) To achieve optimum IPC-A620 insulation crimps, use this insulation OD range.
(2) Overall insulation OD specification for terminal.
(3) The terminals above are reeled parts only. Customer to cut off terminal from reel.
DEFINITION OF TERMS
Doc No: ATS-6382711HM Release Date: 11-18-13
Revision: A
Application Tooling
Specification Sheet
Wire Size
AWG
mm²
18-20 1.50 - 0.50 1.75 -2.50 .069 -.098
BRUSH
CONDUCTOR
CRIMP HEIGHT
Revision Date: 11-18-13
Insulation Diameter
Terminal Insulation
IPC/WHMA-A620 (1)
Maximum (2)
mm
In.
mm
3.00
STRIP LENGTH
BELL MOUTH
CUT-OFF
TAB
UNCONTROLLED COPY
TYPE 4C
Hand Crimp Tool
Order No. 63827-1100
Strip Length
In.
mm
In.
.118
5.00-6.00 .197-.236
INSULATION CRIMP
SEAM
WIRE
Page 1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 63827-1170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for molex 63827-1170

Summary of Contents for molex 63827-1170

  • Page 1 Hand Crimp Tool for Ring Tongue Terminal TYPE 4C Application Tooling Specification Sheet Tool Kit Hand Crimp Tool Order No. 63827-1170 Order No. 63827-1100 FEATURES A full cycle ratcheting hand tool ensures complete crimps Ergonomically designed soft handles Precisely designed crimping profiles with simple contact positioning...

  • Page 2: Installation

    1. Pull Force should be measured with no influence from the insulation crimp. 2. The above specifications are guidelines to an optimum crimp. CAUTION: Install only Molex terminals listed above with this tool. Do not crimp hardened objects as damage can occur to the tool or die.

  • Page 3: Operation

    Hand Crimp Tool for Ring Tongue Terminal To remove the locator 1. Open the crimp hand tool. 2. Swing the existing locator open and away from the hand tool. 3. Firmly press down on the brass pivot shaft with your thumb, while pulling the locator up.

  • Page 4: Maintenance

    Hand Crimp Tool for Ring Tongue Terminal INSULATION CONDUCTOR 12. Visually inspect the crimped terminal for proper PUNCH PUNCH crimp location. WIRES AGAINST LOCATOR STOP Note: The tamper proof ratchet action will not LOCATOR release the tool until it has been fully closed. WIRE For the Battery Power Tool: 1.

  • Page 5: Warranty

    12.7mm (1/2”) long, so there is no crimping of the insulation. Pull the terminal and wire at a rate no faster than 25mm (1.00”) per minute. See the Molex web site for the Quality Crimp Handbook for more information on pull testing.
  • Page 6 Order No. Description 63810-1050 Hand Crimp Frame (Short) 63810-1000 Hand Crimp Frame (Long) 63827-1170 63816-0200 Battery Power Tool (110 V) 63816-0300 Power Crimp Head 63816-0250 Battery Power Tool (220 V) 63816-0300 Power Crimp Head Applications for the Tool Kit Hand Crimp Tool...

  • Page 7: Hand Tool Parts List

    Hand Crimp Tool for Ring Tongue Terminal HAND TOOL PARTS LIST Item Number Order Number Description Quantity 63810-1000 Hand Crimp Frame (Long) 63827-1170 Tool Kit with Locator 63827-1175 Locator (only) M4 X 8mm LONG BHCS RATCHET RELEASE SCREW WITH TOOL KIT...

  • Page 8: Power Head Parts List

    M4 by 8 Long BHCS M4 by 18 Long BHCS M4 by 10 Long BHCS Figure 13 Visit our Web site at http://www.molex.com UNCONTROLLED COPY Doc No: ATS-6382711HM Release Date: 11-18-13 Page 8 of 8 Revision: A Revision Date: 11-18-13...
