FUEL AND IGNITION
2014-2017 Yamaha
Bolt 950 & SCR950
I n s t a l l a t i o n I n s t r u c t i o n s
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
22-035
www.powercommander.com
2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
PARTS LIST
1
Power Commander
1
USB Cable
1
Installation Guide
2
Power Commander Decals
2
Dynojet Decals
3
Velcro strips
1
Alcohol swab
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
THE LATEST POWER COMMANDER
SOFTWARE AND MAP FILES CAN BE
DOWNLOADED FROM OUR WEB SITE AT:
www.powercommander.com
2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 1
Advertisement
Related Manuals for Dynojet PCV F/I
Summary of Contents for Dynojet PCV F/I
- Page 1 SOFTWARE AND MAP FILES CAN BE DOWNLOADED FROM OUR WEB SITE AT: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 1...
-
Page 2: Usb Connection
INPUT 1 you can alter your map based on gear position and setup gear dependent kill times when using a quickshifter. Wire connections: Analog- This input is for a 0-5v signal such as To input wires into the PCV first remove the rubber engine temp, boost, etc. Once this input plug on the backside of the unit and loosen the is established you can alter your fuel curve screw for the corresponding input. Using a 22-24 based on this input in the control center gauge wire strip about 10mm from its end. Push the software. wire into the hole of the PCV until is stops and then tighten the screw. Make sure to reinstall the rubber Crank- Do NOT connect anything to this port unless plug. instructed to do so by Dynojet. It is used to transfer crank trigger data from one module to NOTE: If you tin the wires with solder it will make another. inserting them easier. 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 2... - Page 3 Velcro to secure the module to the top of the ECM. If using the Velcro, clean the surface with the supplied alcohol swab prior to applying the Velcro. FIG.C Route the PCV harness forward going under the frame tubes directly under the seat, and then upward along the backbone of the frame and towards the engine (Fig. C). PCV harness 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 3...
- Page 4 FIG.D Locate and unplug the stock Crank Position Sensor connectors (Fig. D). This connector pair is located just above the front sprocket cover. FIG.E 10 Plug the pair of matching PCV connectors in-line of the stock CPS connectors (Fig. E). FIG.F Rear Inj 11 Locate and unplug the stock wiring harness from the Front and Rear Cylinder Fuel Injectors, located directly on top of the intake manifold (Fig. F). Front Inj 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 4...
- Page 5 FIG.G 12 Plug the matching pair of PCV Injector leads with the ORANGE colored wires in-line of the FRONT Cylinder Fuel Injector and stock wiring harness. 13 Plug the matching pair of PCV Injector leads with the YELLOW colored wires in-line of the REAR Cylinder Fuel Injector and stock wiring harness (Fig. G). FIG.H 14 Locate and unplug the Throttle Position Sensor connector (Fig. H). This connector is located on the rear of the throttle bodies. FIG.J 15 Plug the matching pair of connectors from the PCV in-line of the stock wiring harness the bike’s TPS (Fig. J). 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 5...
-
Page 6: Optional Inputs
16 Locate and unplug the 12 volt wire (BLACK/RED) from the Front Cylinder Ignition Coil, the signal wire (GREY/RED) from the Rear Cylinder Ignition Coil, and the signal wire (ORANGE) from the Front Cylinder Ignition Coil (Fig. K). 12v, BLK/RED 17 Plug the pair of RED/WHITE wires with spade terminals of the PCV in-line of FIG.L the Front Ignition Coil spade and the stock BLACK/RED wire. 18 Plug the pair of BLUE & WHITE/BLUE leads with spade terminals of the PCV in-line of the Rear Ignition Coil spade and the stock GREY/RED wire. 19 Plug the pair of GREEN & WHITE/GREEN leads with spade terminals of the PCV in-line of the Front Ignition Coil spade and the stock ORANGE wire (Fig. L). Optional Inputs: Speed input location - WHITE/YELLOW wire of vehicle speed sensor rear of the front drive sprocket 12v for Auto-tune - BLUE wire of 3-pin connector for tail light 22-035 www.powercommander.com 2014-2017 Yamaha Bolt 950 & SCR950 - PCV F/I - 6...
