2016 Ski-Doo 1200
I n s t a l l a t i o n I n s t r u c t i o n s
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
I25-028
www.powercommander.com
Snowmobile
2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
PARTS LIST
1
Power Commander
1
USB Cable
1
Installation Guide
2
Power Commander Decals
2
Dynojet Decals
2
Velcro Strip
1
Alcohol Swab
3
Zip Tie
2
Posi-tap
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
YOU CAN ALSO DOWNLOAD THE
POWER COMMANDER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2016 Ski-Doo 1200 PCV - 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynojet PCV I25-028
Summary of Contents for Dynojet PCV I25-028
- Page 1 2016 Ski-Doo 1200 Installation Guide Snowmobile Power Commander Decals Dynojet Decals I n s t a l l a t i o n I n s t r u c t i o n s Velcro Strip Alcohol Swab Zip Tie...
- Page 2 Crank- Do NOT connect anything to this port unless unit and loosen the screw for the corresponding instructed to do so by Dynojet. It is used to input. transfer crank trigger data from one module to 2. Using a 22-24 gauge wire, strip about 10mm another.
- Page 3 FIG.A Release the straps securing the side panels as shown in Figure A. FIG.B Remove the front cover as shown in Figure B. FIG.C With the side panels open and front covers removed, loosen the necessary bolts on the airbox to lift the air box and headlight assembly off of the engine. Leave the airbox and headlight on the sled, but lift it off the cylinder head and prop it up with a 2x4 to allow access to the injector connectors as shown in Figure C.
- Page 4 FIG.D Using the supplied velcro, secure the PCV to the side of the battery as shown in Figure D. Make sure to clean both surfaces with the alcohol swab before attaching. FIG.E Route the PCV wiring harness along side the main harness up from the battery and over the cylinder head as shown in Figure E.
- Page 5 FIG.G PCV cable Locate the injectors on the cylinder head as shown in Figure G. Unplug the factory connectors from the injectors. Attach the connectors from the PCV to the injectors and factory connectors as shown in Figure G. Replace the front cover and side panels. fuel injector EFI Tuning with PCV The Power Commander makes fueling changes off of the numbers in the map stored in the Power Commander.
