- Page 1 M 2 M ‐ 7 2 0 ‐ A Version 1.20 M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：1...
-
Page 2: Table Of Contents
Q1: PWR LED indication of M2M-720-A is always turned off…………. 3 Q2: SA1 and SA2 of M2M-720-A is always turned on………………….. 3 Q3: SA1 and SA2 LED of M2M-720-A flash slowly at the same time and keep the state long………………………………………………………… 3 Q4: The audio quality of M2M-720-A is bad…………………………….. -
Page 3: Q1: Pwr Led Indication Of M2M-720-A Is Always Turned Off
Client: Please check server’s DNS and network settings whether they are all correct or not in “Standard Config” page. Q3: SA1 and SA2 LED of M2M-720-A flash slowly at the same time and keep the state long. A3: It means M2M-720-A can’t establish the connection with the other M2M-720-A. - Page 4 M2M-720-A. About VxComm Utility => 1. please refer to http://www.icpdas.com/products/Software/VxComm/vxcom m.htm 2. The user can click “Search Servers” button to start the scan function. About MiniOS7 Utility => 1. please refer to http://www.icpdas.com/download/minios7.htm 2. The user can click “Search” button to start the scan function.
- Page 5 If the M2M-720-A has a real IP and has an internet connection. The user can print current network settings by Com Port (RS- 232). Step1: Connect PC and the M2M-720-A by RS-232 cable. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：5...
- Page 6 Step2: Open Com Port program. We used “Hyper Terminal” of Microsoft Window XP to test here. Step3: Set communication setting of Com Port. (Baud rate = 115200, data bits=8, parity=none, stop bits=1, flow control=none). M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：6...
- Page 7 Step4: Press Call icon. Step5: Set SW1=OFF, SW2=OFF. Step6: Press the Trigger Button about 40 second after power on. Step7: It will show M2M-720-A’s IP in “Hyper Terminal”(ex: IP Address = 192.168.0.211). M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：7...
- Page 8 [Another solution] The user can recover the default network settings by DIP Switch and Trigger button (ex: SW2= ON, SW1= OFF and press the TB about 40 second after power on). M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：8...
- Page 9 IP and version current IP and To press the TB about 40 information from Com Port(RS-232). version second after power on Normal state; It will not change any Normal setting The other states setting and data. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：9...
-
Page 10: Q7. I Can't Open The Webpage Of The M2M-720-A
Q7. I can’t open the webpage of the M2M-720-A. Step1: Please confirm the network settings of the M2M-720-A. (The user can refer to “Q6. If I forgot the network settings, how can I do?”) Step2: Confirm the network settings of the PC have the same domain and different IP with the M2M-720-A. -
Page 11: Q8. Client Can't Connect To Server
“Server IP(*)” of client is the same with “IP Address” of server. “Communication Port” of server and client are the same. “Operation Mode” of client is “VSoIP Client”. “Operation Mode” of server is “VSoIP Server”. Client’s “Standard Config” webpage M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：11... - Page 12 The user can test the network ability by the webpage (ex: http://192.168.1.217/) of server or client. Please click the “Network Tools” hyperlink text on the left window of the webpage and then click “Ping Command” M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：12...
- Page 13 “Start” button to start the test and then click the “Refresh” button to get the result. If the result is 0% packet loss, it means the server’s IP is effective. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：13...
- Page 14 MIS or Internet Service Provider, or the user can test the communication ports are available or unavailable by network exploration utility. Ex: NMAP. About the NMAP, please refer to http://nmap.org/, the user can M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：14...
- Page 15 The user can test the communication ports by nmap.exe <Server IP> (ex: C:\nmap.exe 61.221.131.37). If the communication port 21, 22, 23, 80, 443(default), 10000, 10001’s state are open. It means the server is OK. NMAP test M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：15...
-
Page 16: Q9: Server And Client Can't Establish Com Port Connection
Client in the “Login list” at Server’s “Operation Mode” page.. Step 2: Confirm Server and Client are at “Pair Connection” mode and it shows “Your Status: Pair Connection with Client (IP)” at Server’s “Operation Mode” page. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：16... - Page 17 Depending on the signal state it might sometimes work, other time it might not. Here, we connect the M2M-720-A and the Com Port device via handshake looped to avoid the Com Port device waits handshake line signals, as shown in below.
- Page 18 M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：18...
-
Page 19: Q10: How To Establish An Etm Connection
M2M-720-A(Server): IP=>192.168.1.217 Mask=>255.255.255.0 M-4132(Client) : IP=>192.168.1.218 Mask=>255.255.255.0 Target (ex: PLC or our ISaGRAF PAC or Modbus TCP device or other Ethernet device): Here we use ip-8847 (ISaGRAF SoftLogic PAC) for this example. IP=>192.168.1.219 Mask=>255.255.255.0 M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：19... - Page 20 “Enter” key to connect to client(M-4132). (About IP: default is 192.168.1.217) Step2: Key in user name (default: root) and password (default: icpdas) and then click “Enter” button to login. Step3: Click “Standard Config” link and “Manual Configure” button. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：20...
- Page 21 And then click “Save Setting” button. System Operation Mode=> VSoIP Client Encryption Mode=>None(default) Key=>_userkey(default) NetWork Host Name=>4132Client1 Connect to Server by=>IP(default) Server IP=>192.168.1.217 Server DNS=>www.serverdns.com(default) Communication Port=>443(default) VPN=>Disable(default) Boot Protocol=>Static IP(default) Static IP Config M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：21...
- Page 22 Step5: Click “Reboot” button to reset device in the left page. Step6: Connect to server (M2M-720-A), the same with Step1. Step7, 8: the same with Step 2, 3. Step 9: Set the device at the “Manual Configure” page by below settings.
- Page 23 If the SA1 led is off, it means the connection is OK. If the SA1 led is flash slowly and continued over three minutes, please recheck the settings are all correct. Step12: Open the web page of Server (M2M-720-A) and Click “Etm Config” link. a. Set Target IP=>192.168.1.219, Configure file=>Configure1 b.Click “Save Setting”...
- Page 24 Step13: Select 4132Client1 in the login list and then click “Start Scan” button and then the “Start Scan” button will become to “Stop Scan” button. M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：24...
- Page 25 “Pair Connection” button. Step16: At this time, the SA2 led of server and client should flash fast. It means the Pair connection is OK. Now, the user can connect to the M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：25...
- Page 26 (M2M-720-A) on the PC. Step17: In this example, the target is ip-8847 (ISaGRAF SoftLogic PAC). So, we use ISaGRAF Workbench to connect target for diagnostic and reprogramming. a. Open the ISaGRAF project and click “link setup” b. Set internet address = 192.168.1.217 (Server IP) c.
