3 — PROGRAMMABLE PARAMETERS
VEHICLE GROUP

Rate Parameters

Accel Rate, M1–M2
Decel Rate, M1–M2
Brake Rate, M1–M2
Fast Stop Rate
Accel Release Rate

Speed Parameters

Min Speed, M1–M2
Max Speed, M1–M2

Speed Limit Type

MultiMode Parameters

Mode Select Type
Coast Decel Rate
Anti-Tiedown
Throttle Parameters
Throttle Type
Throttle Deadband
Throttle Max
Throttle Map
Pot Low Check
Sequencing Parameters
Interlock Normally Open
Sequencing Delay
Static Return to Off (SRO)
High Pedal Disable (HPD)
Main Cont Interlock Type
Main Cont Open Delay
Main Contactor Check
Brake Parameters
Brake Fault Check
Brake Delay
Brake Hold Voltage
Brake Driver Type
Anti-Rollback Time
Emergency Reverse
Parameters
Wiring Check
Speed
Direction Interlock
Time Limit
Accel Rate
Switch Closed
24
MOTOR & CONTROL GROUP
Motor Parameters
Min Motor Voltage
Nominal Motor Voltage
Nominal Motor Frequency
Max Motor Speed
Number of Motor Poles
Encoder Pulses/Revolution
Swap Encoder Direction
Failsafe Delay
Control Parameters
P Gain
I Gain
Accel Slip
Regen Slip
Slip Boost
Pull-Out Slip
Accel Slip Voltage
Regen Slip Voltage
Accel Comp
Regen Comp
Regen Voltage Offset
*1230-2xx1 models only.
SYSTEM GROUP
Battery Parameters
Full Voltage
Empty Voltage
BDI Reset Battery Voltage
Battery Recharge Level
Low Voltage Level
Hourmeter Parameters
Enable Total Service Hours
Enable Drive Service Hours
Adjust Hours
Set Total Hours
Set Drive Hours
Total Service Hours
Drive Service Hours
Total Disable Hours
Drive Disable Hours
Drive Disable Speed
Service Total Expired
Service Drive Expired
Maximum Regen Flux
Hydraulics Parameters
Lift PV Max
Lift PV Min
Lift PV Accel Rate
Lift PV Decel Rate
Lower PV Max
Lower PV Min
Lower PV Accel Rate
Lower PV Decel Rate
PV Dither
Pump Start Delay
Pump BDI Lockout
Lift PV Hold Delay
Load Hold Delay
Open Hold Load During Lift
Hyd Throttle Type
Hyd Throttle Deadband
Hyd Throttle Max
Hyd Throttle Map
Max Pump Run Time
Other System Parameters
Power Save Delay
Mux Inputs Enabled *
Inhibit Input Type
Auxiliary Output Type *
Fault Code
Curtis 1230 Manual,
*
Rev. C
