APPENDIX C: SPECIFICATIONS
Table C-1 SPECIFICATIONS: 1230 CONTROLLER
Operating voltage range
Nominal input voltage
PWM operating frequency
Electrical isolation to heatsink
KSI input current (no contactors engaged)
Logic input voltage
Logic input current
Nominal output line-to-line voltage (rms)
Max. output frequency
Operating ambient temp. range
Storage ambient temperature range
MOSFET overtemperature cutback
MOSFET undertemperature cutback
Package environmental rating
Weight
Dimensions (L×W×H)
Regulatory compliance
MODEL
NUMBER
1230-2001
-2002
1230-2101
-2102
1230-2201
-2202
1230-2301
-2302
1230-2401
-2402
-2403
*
Controller mounted to 250 × 250 × 5 mm aluminum plate,
with continuous 5 kph airflow perpendicular to back of plate,
and 25°C ambient temperature.
C-1 A-6
APPENDIX C

SPECIFICATIONS

16 to 32V
24 V
16 kHz
500 V ac (minimum)
90 mA without programmer or speed encoder
170 mA with programmer and SKF speed encoder
>7.5 V High; <1 V Low
10 mA (nominal)
15 V
>200 Hz
-40°C to 50°C (-40°F to 122°F)
-40°C to 85°C (-40°F to 185°F)
linear cutback starts at 100°C (212°F); complete cutoff at 110°C (230°F)
approx. 50% motor current at -25°C (-13°F); complete cutoff at -40°C (-40°F)
IP53
1.1 kg (2.2 lbs)
164 × 146 × 57 mm (6.5" × 5.8" × 2.3")
EMC emissions: EN50081-2/08.93
EMC immunity: EN50082-2: 1995
Safety, uncontrolled runaway: EN1175
UL Recognized Component; meets UL583 dielectric test.
NOMINAL
BATTERY 2 MIN
*
VOLTAGE RATING
(volts) (amps)
24 60
24 60
24 90
24 90
24 120
24 120
24 150
24 150
24 200
24 200
24 200
MODEL-SPECIFIC FEATURES
1 HOUR INTERNAL
*
RATING MAIN MULTIPLEXER
(amps) CONTACTOR INTERFACE
30
✓
30 —
40
✓
40 —
50
✓
50 —
60 —
60 —
80 —
80 —
80 —
1312 TWO
AUXILIARY CAN
OUTPUTS INTERFACE
—
✓ ✓
— — —
—
✓ ✓
— — —
—
✓ ✓
— — —
—
✓ ✓
— — —
—
✓ ✓
— — —
—
✓ ✓
