PROGRAMMABLE PARAMETERS

The 1230 controller has a number of parameters that can be programmed using
a Curtis 1311 handheld programmer or 1314 PC programming station. These
programmable parameters allow the vehicle's performance to be customized to
fit the needs of individual vehicles or vehicle applications. For information on
programmer operation, see Appendix B.

PROGRAMMING MENUS

The programmable parameters are grouped into three main categories (vehicle,
motor & control, system), and into additional subgroups, each with its own
programming menu.
VEHICLE PARAMETER GROUP
— Rate
— Speed
— Multimode
— Throttle
— Sequencing
— Brake
— Emergency Reverse
MOTOR & CONTROL PARAMETER GROUP
— Motor
— Control
SYSTEM PARAMETER GROUP
— Battery
— Hourmeter
— Hydraulic
— Other
A complete list of the individual parameters is presented on the next page.
The parameters are described in the charts that follow. For each parameter, the
charts provide:
• parameter name as it appears in the programmer display,
• allowable range,
• description of the parameter's function and, where applicable,
suggestions for setting it.
We urge you to read Section 5, Initial Setup, before adjusting any of the
parameters.
Even if you opt to leave most of the parameters at their default settings,
it is imperative that you perform the procedures outlined in Section 5,
which set up the basic system characteristics for your application.
