7 — DIAGNOSTICS & TROUBLESHOOTING
7
54

DIAGNOSTICS AND TROUBLESHOOTING

Diagnostic information is provided by the fault codes flashed by the Status
LED, the fault display on the Spyglass gauge, and the Faults menu on the 1311
programmer. Refer to the troubleshooting chart at the end of this section for
suggestions covering a wide range of possible faults.

LED DIAGNOSTICS

The Status LED output at J1-Pin 17 provides either fault codes (Table 3) or fault
categories (Table 4), depending on how the Fault Code parameter is set. The
built-in Status LED located on top of the controller always provides fault codes.
LED Fault Codes
During normal operation, with no faults present, the Status LED flashes steadily.
If the controller detects a fault, a 2-digit fault code is flashed until the fault is
corrected. For example, code "3,2"—main contactor fault—appears as:
¤¤¤ ¤¤
( 3 , 2 )

Table 3 STATUS LED FAULT CODES

LED CODES
LED off
solid on
0,1 ¤
■
1,2 ¤ ¤¤
1,3 ¤ ¤¤¤
1,4 ¤ ¤¤¤¤
2,1 ¤¤ ¤
2,2 ¤¤ ¤¤
2,3 ¤¤ ¤¤¤
2,4 ¤¤ ¤¤¤¤
3,1 ¤¤¤ ¤
3,2 ¤¤¤ ¤¤
3,3 ¤¤¤ ¤¤¤
4,1 ¤¤¤¤ ¤
4,2 ¤¤¤¤ ¤¤
4,3 ¤¤¤¤ ¤¤¤
4,4 ¤¤¤¤ ¤¤¤¤
5,1 ¤¤¤¤¤ ¤
5,2 ¤¤¤¤¤ ¤¤
5,3 ¤¤¤¤¤ ¤¤¤
Note: Only one fault is indicated at a time. Faults are not queued up.
¤¤¤ ¤¤
( 3 , 2 )
EXPLANATION
no power or defective controller
controller or microprocessor fault
controller operational; no known faults
motor speed encoder or failsafe fault
motor overcurrent or wiring fault
SRO sequencing error
throttle wiper high
emergency reverse wiring fault
HPD sequencing error
throttle wiper low
tiller multiplexer fault
main contactor or precharge fault
brake fault
expired hourmeter timer
battery over-/under-voltage
controller over-/under-temperature
anti-tiedown fault
controller failure
controller failure
controller failure
