Through the monitor menu, the 13XX programmers provide access to real-time
data during vehicle operation. This information is helpful during diagnostics
and troubleshooting, and also during programmable parameter adjustment.
ITEM
MOTOR + BATTERY
Battery Voltage
BSOC
Motor Speed
Motor Voltage
Motor Frequency
Slip
INPUTS
Throttle Input
Interlock Switch
Forward Switch
Reverse Switch
Mode Switch
Emergency Reverse Switch
Inhibit Input
Speed Limit
Horn Switch
Hyd Throttle Input
Lift Switch
Lower Switch
OUTPUTS
Aux Output 1
Aux Output 2
Prop Valve PWM
Load Hold Valve
CONTROLLER
Temperature
Main Contactor
Total Hourmeter Hours
Drive Hourmeter Hours
Fault Position

MONITOR MENU

MONITOR MENU
VALUE DISPLAYED
Voltage at KSI, in volts.
Battery state of charge.
Motor speed, in revolutions per minute.
Motor voltage, in volts.
Motor frequency, in hertz.
Motor slip frequency, in hertz.
Throttle request: traction throttle.
Interlock switch, on/off.
Forward switch, on/off.
Reverse switch, on/off.
Mode switch, on/off.
Emergency reverse switch, on/off.
Inhibit input, on/off.
Speed limit request from pot or switch.
Horn switch on or off.
Throttle request: hydraulic throttle.
Lift switch, on/off.
Lower switch, on/off.
Aux 1 driver output.
Aux 2 driver output.
Proportional valve PWM output.
Load hold valve driver output.
Controller internal temperature (MOSFETs).
Main contactor, open/closed.
Total service hourmeter, in hours.
Drive service hourmeter, in hours.
Additional fault information.
