1. Remove the sealing bar by lifting it from the cylinders. See Figure 5: Removing the Sealing
Bar on page 26.
2. Remove the Teflon tape (1) that protects the sealing wire.
3. Remove the screws (2) at the bottom of the sealing bar and remove the sealing wires (3).
4. Replace the Teflon tape on the sealing bar.
a. Pull the Teflon tape from the top of the sealing bar (4).
b. Clean the sealing bar with a dust-free cloth.
c. Apply a new piece of Teflon tape of the same length on the sealing bar.
5. Replace the sealing wires.
a. Cut a new piece of sealing wire or cutting wire at the length of the sealing bar plus
approximately 15 cm.
b. First place the wire on one side of the sealing bar by tightening the screws (2).
c. Place the other end of the wire in its location and tension it with pliers. Now fasten it by
tightening the screws.
d. Cut both ends of the wire.
6. Replace the Teflon tape on the sealing wire.

Figure 5: Removing the Sealing Bar

Figure 6: Replacing the Sealing Wire
