LR/ELR LASER SCAN ENGINE

The tables below list reader settings as well as symbology settings for the Long Range
Laser (LR) or Extra Long Range Laser (ELR) scan engine.

READER SETTINGS TABLE

LR/ELR
AIM Duration
Decode Time-out

SYMBOLOGY SETTINGS TABLE

LR/ELR/2D
Codabar
CLSI Editing
NOTIS Editing
Select Length
Code 128
GS1-128
Field Separator
Replacement
ISBT 128
Description
0~255, in units of 1 second.
Enter 0 if aiming is not desired.
Set the maximum time for decoding to continue during a
scan attempt.
5~99, in units of 0.1 second.
Description
When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and
tenth characters of a 14-character Codabar barcode.
The 14-character barcode length does not include
start/stop characters.
Decide whether to include the start/stop characters in the
data being transmitted.
NOTIS Editing is to strip the start/stop characters, i.e.
to disable "Transmit Start/Stop Characters".
Any Length
One or two fixed lengths
Range (1~55)
Decide whether to replace the field separator. If the
barcode contains Field Separator "0x1D", it will be
changed to the desired Field Separator. For example, type
the desired character ";" (semicolon) as the new field
separator. Then if the barcode contains Field Separator
"0x1D", it will be changed to ";".
Appendix III
Default
No aiming
3.0 sec.
Default
Disable
No
No
Any Length
Enable
Enable
No
Enable
71
