CipherLab 8000 Series User Manual page 76

FORGE Batch Application Generator
Verify Check Digit Select one of the three calculation formulas to verify the
check digit. If the check digit is incorrect, the barcode will
not be accepted.
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Select Length
Negative Barcode
Plessey
Convert to UK Plessey When applied, each occurrence of the character "A" in the
barcode data will be replaced by the character "X".
Transmit Check Digit Decide whether to include the two check digits in the data
being transmitted.
Telepen
Original Telepen The original Telepen includes numeric characters.
(Numeric)
AIM Telepen (Full AIM Telepen (Full ASCII) includes all the alphanumeric and
ASCII) special characters.
GS1 Databar-14/Expanded
GS1 Transmit Decide whether to include Code ID ("]e0") will be included
Databar-14 Code ID in the data being transmitted.
GS1 Transmit Refer to GS1 Databar -14.
Databar Code ID
Expanded
Transmit Application Decide whether to include the Application ID ("01") in the
ID data being transmitted.
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
GS1 Databar Limited
Transmit Code ID Refer to GS1 Databar -14.
Transmit Application Refer to GS1 Databar -14.
ID
Transmit Check Digit Refer to GS1 Databar -14.
EAN-8
Convert to EAN-13 The EAN-8 barcode will be expanded into EAN-13, and the
next processing will follow the settings configured for
EAN-13.
68
User Guide
Single Modulo 10
Double Modulo 10
Modulo 11 & 10
Last digit not transmitted
Both digits transmitted
Both digits not transmitted
One or two fixed lengths
Range
Single Modulo
10
Both digits
transmitted
0~127
Disable
Disable
No
Yes
Disable
Yes
No
Disable
Yes
Yes
Yes
Disable
Yes
Yes
Yes
Enable
No
