SICK FLOWSIC600 Manual
Ultrasonic gas flow meter
Hide thumbs
Also See for FLOWSIC600:
- Technical information (262 pages) ,
- Operating instructions manual (102 pages) ,
- Operating instructions manual (100 pages)
Related Manuals for SICK FLOWSIC600
Summary of Contents for SICK FLOWSIC600
- Page 1 A D D E N D U M T O O P E R A T I N G I N S T R U C T I O N S FLOWSIC600 Ultrasonic Gas Flow Meter FLOWSIC600 DRU Ultrasonic gas flow meter for upstream applications...
- Page 2 SICK Engineering GmbH assumes no liability for the correctness of an unauthorized translation. Please contact the publisher in case of doubt. Legal information Subject to change without notice. © SICK Engineering GmbH. All rights reserved. FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH...
- Page 3 NOTICE Hazard which could result in property damage. Information Symbols Important technical information for this product Important information on electric or electronic func- tions Supplementary information FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH...
-
Page 4: Table Of Contents
FLOWSIC600 DRU 3" and 4" ........ -
Page 5: Important Information
Important Information FLOWSIC600 Important Information About this document For your safety FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... -
Page 6: About This Document
Read the corresponding Operating Instructions carefully before using the FLOWSIC600 DRU. Special attention must be paid to all safety instructions and warnings for assembly, installation and operation! FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... -
Page 7: Flowsic600 Dru
FLOWSIC600 DRU FLOWSIC600 FLOWSIC600 DRU Product description Technical data Installation instructions FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... -
Page 8: Product Description
FLOWSIC600 DRU is an innovative ultrasonic dual-path gas meter for upstream applications based on FLOWSIC600. The meter has a full-bore design and includes a 10D inlet piping for piping diameters ≤ 4“. For larger diameters an additional specially for DRU manufactured 10D inlet piping is included in the scope of delivery. -
Page 9: Application Range
Application range 2.1.2 Maximum volume flow rate Qmax is limited for gas pressures above 450 psig / 31 barg. The application range for different diameters of FLOWSIC600 DRU is shown in Fig. 2. Figure 2 Application range FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... -
Page 10: Liquid Indication Diagnosis
The liquid indication diagnosis uses real-time monitoring of multiple diagnostic parameters of the FLOWSIC600 DRU in order to identify wet gas conditions (liquids in the gas stream such as liquid hydrocarbons, water and oil). Liquids in the gas stream are usually undesired in the gas production process and may require appropriate actions such as process optimization or consideration for meter readings. -
Page 11: Installation
Make sure that the meter is mounted in the correct orientation ( Fig. 3).The flow direc- tion is marked on the meter body. FLOWSIC600 DRU must be installed as shown in Fig. 3 with upstream flow condi- tioner type CPA 55E. Installation without upstream flow conditioner or with another type of flow conditioner will cause higher uncertainty of measurement. -
Page 12: Electrical Installation
FLOWSIC600 DRU Electrical Installation 2.3.2 The output configuration of FLOWSIC600 DRU can be taken from the instrument data- sheet in the manufacturer data record (MDR) and from the wiring diagram inside the rear housing cover. For instructions on the electrical installation please refer to OI FLOWSIC600, chapter 3.4. -
Page 13: Technical Data
2 DO and 1 FO: 30 V, 10 mA Passive, galvanically isolated, open collector, fmax = 6 kHz (scalable) Interfaces RS-485 (2x, for configuration data output and diagnosis) FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... - Page 14 Weight 3 inch: 48 kg; 4 inch: 85 kg; 6 inch: 250 kg Electrical connection Voltage 12 ... 28.8 V DC Power consumption ≤ 1 W FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH...
-
Page 15: Dimensional Drawings
All dimensions in mm (in). 3" 1040 76,66 250.5 355.5 226.3 (40.94) (2.90) (9.86) (14.00) (8.27) (8.91) 4" 1300 97.18 258.8 51.18 (3.83) (10.20) (15.60) (10.83) (10.19) FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... -
Page 16: Flowsic600 Dru 6
FLOWSIC600 DRU FLOWSIC600 DRU 6" 2.5.2 All dimensions in mm (in) 6" 1950 146.4 355.6 (76.77) (5.76) (11.22) (18.20) (14.00) FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH... - Page 17 FLOWSIC600 DRU FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V 1-6/2018-05 · © SICK Engineering GmbH...
- Page 18 E-Mail sales@sick.co.nz United Arab Emirates China Norway E-Mail sick@sick.no United Kingdom Denmark Poland E-Mail sick@sick.dk Finland Romania Vietnam France Russia Germany Singapore Hong Kong Slovakia E-Mail mail@sick-sk.sk Hungary Slovenia India South Africa www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...
Need help?
Do you have a question about the FLOWSIC600 and is the answer not in the manual?
Questions and answers
Need to change battery on 600 model
To change the battery on the SICK FLOWSIC600 model, follow these steps:
1. Only trained staff may replace the battery.
2. A warning is automatically generated when battery life drops below 15%, and after 8.5 years, a forced replacement warning appears.
3. Open the display protection flap by loosening its screw.
4. Swivel down the display unit and loosen the four screws using an Allen key.
5. Ensure the external power supply is active before disconnecting the old battery.
6. Carefully disconnect and remove the old battery from its holder.
7. Unpack the new battery and check for any visible damage. Do not use a damaged battery.
8. Insert the new battery into the holder and connect it while the external power supply remains active.
Only use a similar battery type supplied by SICK to maintain safety standards.
This answer is automatically generated
