SimCom SIM5300E Hardware Design page 50

Sleep mode
GSM/GPRS supply current
Voice Call
GSM 900
DCS1800
DATA mode, GPRS ( 1 Rx,4 Tx ) CLASS 12
GSM 900
DCS1800
DATA mode, GPRS ( 3Rx, 2 Tx ) CLASS 12
GSM 900
DCS1800
DATA mode, GPRS ( 4Rx, 1 Tx ) CLASS 12
GSM 900
DCS1800
DATA mode, EGPRS ( 1Rx, 4 Tx )
GSM 900
DCS 1800
DATA mode, EGPRS ( 3 Rx, 2 Tx )
GSM 900
DCS 1800
DATA mode, EGPRS ( 4Rx, 1 Tx )
SIM5300E_Hardware_Design_V1.02
Sleep mode @ BS-PA-MFRMS=2 1.9mA
Sleep mode @ BS-PA-MFRMS=5 1.5mA
Sleep mode @ BS-PA-MFRMS=9 1.4mA
@power level #5 <300mA,Typical 232mA
@power level #0 <250mA,Typical 161mA
@power level #5 <660mA,Typical 503mA
@power level #0 <530mA,Typical 325mA
@power level #5 <500mA,Typical 412mA
@power level #0 <400mA,Typical 273mA
@power level #5 <300mA,Typical 236mA
@power level #0 <250mA,Typical 165mA
@power level #8<500mA,Typical 425mA
@power level #2<500mA,Typical 313mA
@power level #8<330mA,Typical 243mA
@power level #2<330mA,Typical 189mA
