<fun>
0
BS-PA-MFRMS=2
1 BS-PA-MFRMS=5
BS-PA-MFRMS=9
4

4.4.2 Sleep Mode 1 (AT+CSCLK=1)

After setting command "AT+CSCLK=1", user can control SIM5300E module to enter or exit the sleep mode 1
(AT+CSCLK=1) by DTR signal. When DTR is in high level and the module does not receive interruptions on air
and hardware (such as a GPIO interruption or data in serial port), SIM5300E will enter sleep mode 1
automatically. In this mode, SIM5300E can still receive paging or SMS from network, but the serial port is not
accessible.
Note: SIM5300E requires to set AT command "AT+CSCLK=1" and ensure DTR at high level to enable
the sleep mode 1; the default value is 0, which cannot make the module to enter sleep mode. For
more details, please refer to document [1].

4.4.3 Wake Up SIM5300E from Sleep Mode 1 (AT+CSCLK=1)

When SIM5300E is in sleep mode 1 (AT+CSCLK=1), the following methods can wake up the module:

Pull down DTR pin.

The serial port will be active after DTR pin is pulled to low level for about 50ms.

Receive a voice or data call from network.

Receive a SMS from network.

4.4.4 Sleep Mode 2 (AT+CSCLK=2)

In this mode, SIM5300E will continuously monitor the serial port data signal. When there is no data transfer
over 5 seconds on the RXD signal and there are no on air and hardware interruptions (such as a GPIO
interruption), SIM5300E will enter sleep mode 2 automatically. In this mode, SIM5300E can still receive
paging or SMS from network but the serial port is not accessible.
Note: SIM5300E requires to set AT command "AT+CSCLK=2" to enable the sleep mode 2; the default
value is 0, which cannot make the module to enter sleep mode. For more details, please refer to
document [1].

4.4.5 Wake Up SIM5300E from Sleep Mode 2 (AT+CSCLK=2)

When SIM5300E is in sleep mode 2 (AT+CSCLK=2), the following methods can wake up the module:

Send data to SIM5300E through main serial port.
SIM5300E_Hardware_Design_V1.02
Current consumption(mA) (sleep mode)
0.65
1.9
1.5
1.4
0.7
23
