Summary of Contents for Sebury BC-2000
-
Page 2: Specifications
Use safety goggles when drilling or ham mering in cable clips. The BC-2000/K2 can store 1000 users with card Every effort has been made to provide accurate and 4-6 digits password codes.It has one relay information, however slight variations can occur. - Page 3 Door detecting switch Brown D_IN +12V Black Blue Electric bolt NC Purple Electric strike: NO Lock Orange BC2000/K2 Common Power Supply BC-2000 POWER +12V GND PUSH Alarm Figure 4 Exit button Grey Electric bolt Electric strike ALARM- Yellow OPEN 5. Wiring...
-
Page 4: Detailed Programming Guide
6. Detailed Programming Guide 6.1. User Settings * Master code # To enter the programming mode 9999 is the default factory master code To exit from the programming mode Note that to undertake the following programming the master user must be logged in 0 New code # New code # To change the master code The master code is any 4-6 digits... - Page 5 To delete a card user by user ID. This option can be used 2 User ID # when a user has lost their card To set a card and PIN user in card and PIN mode ( 3 1 # ) Add the card as for a card user To Add a card and PIN user(The PIN is any 4-6digits Press * to exit from the programming mode...
- Page 6 Toggle mode 4 0 # Every time a valid tag/card or PIN is read/input in Toggle Toggle mode Mode, the relay changes state, which will not turn back until read card or input PIN again. 6.3. Alarm Settings, Door Detecting Alarm output time To set the alarm output time (1~3 minutes) 5 1~3 #...
-
Page 7: Technical Specification
Negative loop, normally closed Keypad Housing Metal Operating Temperature -40℃ to 60℃ (-40 F to 140 F) × 82 × 28mm L128 mm W mm H (BC-2000) Dimensions L135 mm×W58 mm×H26 mm (K2) Weight 500g 10. Package Listing Name Model no. Qnty Remark... - Page 8 BC-2000/K2 Quick Reference Programming Guide * Master code # To enter the programming mode 9999 is the default factory master code To exit from the programming mode Note that to undertake the following programming the master user must be logged in...
