Summary of Contents for Sebury sTouch2
- Page 1 / 2s INSTRUCTION MANUAL 45mm 83mm 160mm 145mm Wide Slim...
-
Page 2: Introduction, Features And Specifications
2. Installation and Wiring Instruction 2.1 Package List QTY Remark Product Name Model/Description Item sTouch2 Color box sTouch2 Access controller sTouch2 instruction Instruction Manual manual sTouch2 Punch sticker sTouch2 Screw Hole Decoration piece Φ6mm×30 mm Expansion Rubber Bung white ΦKA4mm×25 mm... -
Page 3: Installation Steps
④stick decoration piece on the anti-dropping screw position. 2.3 Wiring Diagram sTouch2 Reader mode sTouch2 Standalone Acess Control mode Access control special power supply Red Black... -
Page 4: User Operation
4. User Operation 4.1 Use Card Open Door Read valid user card once, the lock opened. 4.2 Use Card and Password Open Door Read valid user card once, then enter 4-6 digits user’s password, press “#”, the lock opened. 4.3 Use Card or Password Open Door Read user card once, the lock opened. -
Page 5: Reset To Factory Default
7. Reset to Factory Default In the state of Power off, the indicator light turn on orange when power on for 1 second, press “*” within 1 second, release it until hearing two shot beep voice, then hear a long beep voice, enter the normal operation state. -
Page 6: Basic Operation
9.1 Basic Operation: Basic Operation Orange Function Remark Flash 6-8 digits new password，#，repeat 6-8 Modify administrator password digits new password，# Read card 1-2000（ID），#，read card ① ② 8 or 10 digits card number Adding 1 card ，# ③ 1-2000（ID），#，8 or 10 digits card Rotate Operation number, # 1-2000（ID），#，4-6 digits user... - Page 7 4-6 digits key +facility code virtual card number output Default 1 Single Key a 4bit output Single Key a 8bit output ⑤ Turn off Alarm Default 1 Turn on Alarm for 1-3 minutes User Options Setting ⑥ IIndicator Light Normally OFF Default 1 Indicator Light Normally ON ⑦...
- Page 8 10.1 Reader Mode As a card reader, the device has the following functions: Enter Administrator Operation Red Flash Function Remark Default Enter administrator operation mode 6-8digits administrator password # 888888 Reader Settings Orange Orange Function Flash Flash Remark 6-8digits new passwords #，repeat Modify Administrator Password 6-8 digits new passwords # Facility code...
-
Page 9: Simple Troubleshooting
1（11100001） 2（11010010） 3（11000011） 4（10110100） 5（10100101） 6（10010110） 7（10000111） 8（01111000） 9（01101001） *（01011010） 0（11110000） #（01001011） 10.2 Standalone Access Control Mode Under this mode: The electric lock can be opened by reading user card or inputting user password on the device or external card reader. Read anti-stress card or input anti-stress password on the device or external card reader to open the electric lock, the external alarm will sound at the same time. - Page 10 E-instruction if you lost the physical one Website: www.sebury.com Alibaba online shop: seburytech.en.alibaba.com Tel: +86 755 86951020 Mobile: +86 13510759940 Email: sales@sebury.com.cn Search “Sebury access control” or “ Sebury + model” Operational Video E-Instruction Introductory Video...
