XFP transceiver modules
Figure 2 Appearance of XFP transceiver modules
Table 2 XFP transceiver module specifications
Item
Central wavelength
Maximum transmission distance
Data rate
Connector type
Fiber Mode
Cable specification
Fiber bandwidth
Output optical power
Receiving sensitivity
Pressure sensitivity
Optical saturation
Specifications
XFP-SX-MM850
850 nm
300 m (984.25 ft)
10.31 Gbps
Duplex LC
MMF
50/125 μm
2000 MHz*km
–7.3 to –1.08 dBm
≤ –11.1 dBm
≤ –7.5 dBm
≤ –1 dBm
2
XFP-LX-SM1310
1310 nm
10 km (6.21 miles)
10.31 Gbps
Duplex LC
SMF
9/125 μm
—
–8.2 to +0.5 dBm
≤ –12.6 dBm
≤ –10.3 dBm
≤ 0.5 dBm
