Matrix
Symptom
Indicates lack of a flame signal.
Boiler will
In order to stay running the flame
not stay lit.
signal must be at least 0.7 µAmps
Boiler Bangs or sounds like a kettle
bangs or while burner is running indicates
hisses
Boiler
Lights Typically an imbalance in the Air
rough or
pulsates
Slight vibration can cause noise in
Fan appears
(This is not a warranty issue)
to be
creating a
noise in the
house
((This is not a warranty issue))
Detected Problem
insufficient flow
to gas ratio
the residence
Making a rubbing noise.
Installation and Operation Instructions
Solution
1. If the Burner light on the Burner (Red) Control is going
out, go to "Burner shutting off".
2. Check condensate drain for blockage and check the inlet
piping for ingested snow or water (if the flame rod gets
wet, it may need to be replaced). Check for resistance
from flame rod to ground, must be an open circuit (O.L),
if not, remove rod and bend it away from the burner
slightly.
3. Check for proper polarity of line and neutral wiring to the
boiler.
1. Ensure the plumbing is as shown in manual. Check to see
if pumps are operating properly and water pressure is
above 15psi. This problem can lead to boiler
overheating!
2. Boiler may be plugging with scale or magnetite, clean
with Fernox DS-40 Descaler and Cleanser (NTI PN:
83450).
3. If glycol is being used the concentration may be to high,
recommend using a concentration lower than 35%.
1. Ensure that the venting lengths are in compliance with
Section 4.0
2. Ensure that the line pressure during operation does not
drop more than 20% from the static line pressure.
3. Momentarily remove the intake vent from the boiler
during ignition, if unit lights smoothly with intake vent
disconnected reconnect and check for proper combustion
if unit maintains smooth operation after ignition. (See
Section 9.0) Calibrate for proper combustion. If
problem persists contact NY Thermal.
4. Heat exchanger may be dirty, remove burner door and
inspect, clean if necessary.
1. Use flexible gas line to isolate the vibration noises
between the gas valve and the line.
Don't hang gas lines from floor joists.
2.
3. Use rubber insulators with gas line supports.
1. If gas valve is not held when the gas nipple is connected,
the force of tightening the fitting can damage the valve,
and warp the fan housing.
2. If pipe is used, the gas line must not create any forces to
the valve, either vertically (weight of line), or horizontally
(misaligned connection)
