Item Part #
36 82762 (82762-1)
37 82099
38 83083
40 83425-1 (82622-
3)
41 83291-2
41 83291-3
42 82368
44 83084
45 83222
46 83553 (83208)
47 81396
48 83551
49 82662
51 83548
52 83160
53 53035
54 83081 (82831)
55 82285
56 83154
56 83363
58 83547
59 83549
60 82457 (83190)
61 82058
62 83550
63a 82754-1 (82984)
64 83555
66 83552
71 81027-1 (83604)
64
Models
Lx150-500, M100(V), Tft60-
399, Ti100-400, Ts80,
VM110, VM110P
Lx150-300, M100(V), T150-
200, Tft60-250, Ti100-200,
Ts80, Tx200, Tx200C
M100(V)
Lx150-200, M100(V)
M100(V)
M100(V)
M100(V), T150-200, Ti100-
150 (CAN), Combi (Ti)
M100V
M100(V)
M100(V)
M100(V)
M100V
Lx150-800, M100(V), Ti100-
400, Ts80
M100V
M100(V)
M100(V)
M100(V)
M100(V)
M100(V)
M100(V)
M100V
M100V
Lx150-400, M100(V), T150-
200, Tft60-399, Ti100-400,
Ts80
M100(V), T150-200, Ti100-
400
M100V
M100(V), Ti100-400
M100V
M100V
Lx150-800, M100(V), T150-
200, Tft60-399, Ti100-400,
Ts80, Tx51-200, Tx151C,
Tx200C, VM110, VM110P
Description
Flame Rod Lx/Ti/Ts/Tft/VM (60-500) (Includes p/n:
82774)
1-1/2" MJ Coupling
Fan Control Matrix
Air Metering Elbow Lx150-200, Matrix
Flue Adapter Assembly 2" CPVC x 3.5" (Models
manufactured before 12/9/2009)
Flue Adapter Assembly 2" CPVC x 4.75" (Models
manufactured after 12/9/2009)
Compression Nut Washer, Water Connection, 3/4"
HRV Assembly Matrix
Plenum Sensor Matrix
Door Safety Switch Matrix
Circulator Pump Grundfos UP15-42B7
Double Collar, 6"
Air Switch Huba 604.E021180
(Set @ .2" wc)
HRV HVC Board
Sentry 2100 Version B3.2
Furnace Blower Matrix
ECM Motor 3/4 HP
Expansion Tank
Fin Tube Coil 20" x 15" (Models manufactured before
12/9/2009)
Fin Tube Coil 22.5" x 18" (Models manufactured after
12/9/2009)
HRV Fan
HRV Pleated Filter x 2
Transformer 24V, 40VA
Ignition Module, Fenwal
HRV Core
PCB Optocoupler
HRV Damper Actuator 24V
Keeper, 6" Collar
Outdoor Sensor 10K
Matrix
