6 | Bosch Climate 5000 Series Multi Zone Ductless Air Conditioner / Heat Pump

2 Components

The air conditioning / heat pump system installation requires the following
components. Use all of the installation parts and components to install the air
conditioner. Improper installation may result in water leakage, electrical shock and
fi re, or equipment failure.
Drain joint
Seal ring
Connecting pipe assembly
Multi-zone installation manual
Transfer connector
NOTE: Pipe sizes may vary between air handler and condensing section connections. To meet diff erent pipe size requirements,
it may be necessary to install an adapter (transfer connector) on the outdoor unit connection.
Magnetic ring (Hitch on the connective cable between the indoor unit and outdoor unit after installation.)
Power cable for connection with external power supply
Table 1
Data subject to change
Liquid side
Gas side
Φ6.35 (1/4 in)
Φ9.52 (3/8 in)
Φ9.52 (3/8 in)
Φ12.7 (1/2 in)
Φ 16 (5/8 in)
05.2019 | Bosch Thermotechnology Corp.
Installation Manual
Parts not included.
Piping kits are available
as an accessory.
Not included, but may be
required - 1 per indoor unit
Not included, but
recommended to use
1 per cable.
Not included (see section 9
for cable requirements)
