1. Cautions on Assembly
There will be some steps where force is necessary.
Please take the proper measures and precautions to not hurt yourself or damage the parts
and follow the instructions as described.
You will need a phillips screwdriver (+ head) for assembly.
Please use the provided pictures as a reference during assembly.
Please be aware that the colours and/or appearance of some parts in the provided pictures
and those provided may be slightly different.
The required program for the M5Stack has already been included.
How to install page is [7. Firmware Installation]
PLEN5Stack https://github.com/plenprojectcompany/PLEN5Stack
When assembling the servo motors, the initial rotational position of the gear on the motors is
important.
The assembly instructions includes initial positioning for the motors.
Please ensure all motors are properly set.
When setting the servo motors, make sure you wait at least 2 seconds after turning the
power switch on until the servo motors automatically set to their initial position.
If the servo motors do not move after 2 full secods, please if check they are connected
properly.
3 / 61
